iOS 15 Image Forensics Analysis and Tools Comparison - Communication and Social Networking Apps
The fourth episode is dedicated to the most analyzed family of applications: communication and social networking apps.
Before I start, I would like to mention that I have
made some corrections to the previous blog post, based on feedback by tool
developers. Also, most of them have confirmed to me that they are working on
improving their parsing capabilities, based on this blog series. I am happy to
support them in that direction!
There are 29 communication and social
networking applications available in Josh Hickman’s acquisition.
The apps are listed below, in alphabetical order.
- BeReal
- Burner
- Clubhouse
- Discord
- Facebook Messenger
- Google Chat
- Google Meet
- Google Voice
- GroupMe
- imoHD
- Kik Messenger
- Line
- Mastodon
- MeWe
- Session
- Signal
- Silent Phone
- Skype
- Snapchat
- Telegram
- Threema
- TikTok
- Truth Social
- Viber
- Wickr Pro
- Wire
Before getting into the details of every single
apps, it’s important to highlight that once an app is installed on an iOS
device, app data is stored in a subfolder in the
/private/var/mobile/Containers/Data/Application/ folder. Some apps can also
store data in a subfolder in the
/private/var/mobile/Containers/Shared/AppGroup. When analyzing an application,
it’s important to check and eventually investigate both areas.
APOLLO has no parsers for third-party apps and ArtEx
only has a parser for Discord, which did not run correctly on the test image,
and a parser for Snapchat.
Each section for each app is structured
similarly: first, a list of the most important files and folders is provided,
then a description of the tools parsing capabilities for that app, and finally
two different tables. The first table provides the details for each action
documented by Josh in the iOS 15 image documentation, and the second table provides
a summary of the tools’ parsing capabilities based on the test results.
As usual, YES means that the value was parsed and parsed correctly, NO means that the value was not parsed, YELLOW means that it was partially parsed, and BLUE means that the value was found elsewhere (i.e., iOS Notification or iOS Cache).
BeReal
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/disk-bereal-RelationshipsContactsManager-contact
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/disk-bereal-RelationshipsFriendsListManager
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/disk-bereal-UploadPostWorker-post-upload
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/disk-bereal-FeedMyPostManager-subject-series
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/AlexisBarreyat.BeReal/fsCachedData
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/AlexisBarreyat.BeReal/Cache.db
Direct parsing of this application is only supported by OXYGEN, but it only includes account information, contacts, posts, and cache. AXIOM, PA, XAMN, and iLEAPP were able to parse a comment to a post from iOS notifications. BeReal parsing was introduced by PA in version 7.64.
Following is the comparison table with the details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
05/05/2023 |
12:10 |
16:10 |
Set profile picture |
HAL |
NO |
NO |
NO |
NO |
NO |
NO |
|
17/05/2023 |
08:27 |
12:27 |
Took & Posted BeReal |
Starbucks/car selfie |
NO |
NO |
NO |
NO |
NO |
NO |
|
18/05/2023 |
15:02 |
19:02 |
Took & Posted BeReal |
Car doors |
NO |
NO |
NO |
NO |
NO |
NO |
|
18/05/2023 |
15:03 |
19:03 |
Left comment on other BeReal |
Nice machine! |
NO |
NO |
NO |
NO |
NO |
NO |
|
18/05/2023 |
15:07 |
19:07 |
Other party commented on BeReal |
(BeReal posted at 15:02) Car doors??? |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
20/05/2023 |
13:43 |
17:43 |
Took BeReal & discarded it |
|
NO |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
13:44 |
17:44 |
Took BeReal |
Trees & playground |
NO |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
13:45 |
17:45 |
Sent BeReal |
(Taken at 13:44) |
NO |
NO |
NO |
NO |
NO |
NO |
The overall results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
YES |
NO |
NO |
NO |
|
Contacts |
NO |
NO |
YES |
NO |
NO |
NO |
|
Posts |
NO |
NO |
YES |
NO |
NO |
NO |
|
Cache |
NO |
NO |
YES |
NO |
NO |
NO |
Burner
Relevant information for this application is stored in these files and folders:
- /private/var/mobile/Containers/Shared/AppGroup/<APP_GUID>/Phoenix.sqlite
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/com.adhoclabs.burner/fsCachedData/
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/com.adhoclabs.burner/Cache.db
Direct parsing of this application is supported by AXIOM and OXYGEN. PA, XAMN, and iLEAPP were able to parse some incoming messages from iOS notifications. Messages and contacts are parsed correctly by both AXIOM and OXYGEN. Audio calls are partially parsed by both tools, as they were not able to determine the call length.
Following is the comparison table with the details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
08/05/2023 |
13:23 |
17:23 |
Obtained phone number |
|
NO |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:25 |
17:25 |
Sent message |
You there? |
YES |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:27 |
17:27 |
Received message |
I am. What number is this? |
YES |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
08/05/2023 |
13:29 |
17:29 |
Sent message |
Burner. What are you doing? |
YES |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:33 |
17:33 |
Received message |
Ah, ok. Nothing in particular. Same as you. |
YES |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
08/05/2023 |
13:37 |
17:37 |
Sent message |
Catching up on some DS9. I can’t believe I never
watched that when it was on-air |
YES |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:46 |
17:46 |
Received message |
It’s a good show. Helps in understanding Picard |
YES |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
08/05/2023 |
13:48 |
17:48 |
Sent message |
That’s what I have heard. Definitely an
underrated show. |
YES |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:49 |
17:49 |
Received message |
It is. Hang on and I’ll send you a picture |
YES |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
08/05/2023 |
13:50 |
17:50 |
Received picture |
Pirate |
YES |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:52 |
17:52 |
Sent message |
Got it. I’ll send one |
YES |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:53 |
17:53 |
Sent picture |
An intelligent man |
YES |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:54 |
17:54 |
Received message |
Got it. I’ll call you in a minute. |
YES |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:55 |
17:55 |
Outgoing audio call |
(~1:30) |
YES |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:58 |
17:58 |
Sent message |
Ok. We got that backwards. You can call me now.
Lol |
YES |
NO |
YES |
NO |
NO |
NO |
|
08/05/2023 |
13:59 |
17:59 |
Incoming audio call |
(0:13) (iOS call logs shows accepted call, Burner
call log shows as missed call) |
YES |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
08/05/2023 |
14:00 |
18:00 |
Incoming audio call |
(0:15) (iOS call logs shows accepted call, Burner
call log shows as missed call) |
YES |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
08/05/2023 |
14:01 |
18:01 |
Received voicemail |
(0:09) |
YES |
NO |
YES |
NO |
NO |
NO |
The overall results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
YES |
NO |
NO |
NO |
|
Contacts |
YES |
NO |
YES |
NO |
NO |
NO |
|
Messages |
YES |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
Calls |
YES |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
Voicemail |
YES |
NO |
YES |
NO |
NO |
NO |
|
Attachments |
NO |
NO |
Cache |
NO |
NO |
NO |
|
Cache |
NO |
NO |
YES |
NO |
NO |
NO |
Clubhouse
Relevant information for this application is stored in these files and folders:
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Preferences/co.alphaexploration.clubhouse.plist
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/co.alphaexploration.clubhouse/csCachedData
Direct parsing of this application is supported
by PA and OXYGEN, but messages were not parsed. AXIOM, PA, XAMN, and iLEAPP were able to parse
some incoming messages from iOS notifications.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
05/05/2023 |
12:19 |
16:19 |
Login |
Login |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
12:21 |
16:21 |
Received message |
Made it to Clubhouse. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
12:22 |
16:22 |
Sent message |
Awesome. Welcome back. |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
12:23 |
16:23 |
Received message |
Thanks. This looks rather limited, eh? |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
12:24 |
16:24 |
Sent message |
It does. WE can try to create a room in a few
minutes. |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
12:26 |
16:26 |
Received message |
Sounds good. We can’t even send photos here, can
we? |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
12:28 |
16:28 |
Sent message |
Nope. Basic DMs. |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
12:29 |
16:29 |
Received message |
I’ll create the room. Give me a moment. |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
12:30 |
16:30 |
Entered room |
(~1:30) |
NO |
NO |
NO |
NO |
NO |
NO |
The overall results for each category and tool
are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
YES |
NO |
NO |
NO |
|
Contacts |
NO |
NO |
YES |
NO |
NO |
NO |
|
Channels / Rooms |
NO |
NO |
YES |
NO |
NO |
NO |
|
Messages |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
Cache |
NO |
NO |
YES |
NO |
NO |
NO |
Discord
Relevant information for this application is
stored in these files and folders:
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/mmkv/mmkv.default
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/com.hammerandchisel.discord/Cache.db
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/com.adhoclabs.burner/fsCachedData/
Direct parsing of this application is supported
by AXIOM, PA, OXYGEN, XAMN, and iLEAPP. Some differences were found in parsing
capabilities. The deleted message was not recovered by any of the tested
tools.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
24/04/2023 |
14:09 |
18:09 |
Sent message |
I know it says “Android Test Images,” but can we
use this server? |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:10 |
18:10 |
Received message |
Sure, I don’t see why not. What are you up to? |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:12 |
18:12 |
Sent message |
Not much. Just sitting here generating data.
Seems that’s my thing. Lol. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:13 |
18:13 |
Received message |
You could do worse. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:14 |
18:14 |
Sent message |
True. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:15 |
18:15 |
Received message |
How’s the phone? |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:16 |
18:16 |
Sent message |
Still cracked. I still can’t believe I dropped it
like that. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:17 |
18:17 |
Received message |
That was painful to watch. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:20 |
18:20 |
Sent message |
Here comes a picture |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:21 |
18:21 |
Sent picture |
Emotet |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:22 |
18:22 |
Received message |
Accurate! I’ll send one. Hang on. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
14:23 |
18:23 |
Received picture |
Ransomware operator |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:23 |
20:23 |
Sent message |
DM’s? |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:24 |
20:24 |
Other party reacted |
Reaction to message sent at 16:23 (thumbs up
emoji) |
NO |
NO |
NO |
NO |
NO |
NO |
|
24/04/2023 |
16:25 |
20:25 |
Received message |
You here? |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:27 |
20:27 |
Sent message |
I am. Hang on and I’ll send a picture. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:28 |
20:28 |
Sent picture |
Cat |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:29 |
20:29 |
Received message |
I’ll send one. Give me a minute. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:31 |
20:31 |
Received picture |
ChatGPT |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:33 |
20:33 |
Sent message |
I will audio call you in just a minute. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:34 |
20:34 |
Outgoing audio call |
(~1:21) |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:36 |
20:36 |
Incoming audio call |
(~1:31) |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:38 |
20:38 |
Received message |
There was your audio call |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:39 |
20:39 |
Sent message |
I will video call you in a moment |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:40 |
20:40 |
Outgoing video call |
(~1:30) |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:42 |
20:42 |
Received message |
I will video call you momentarily |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:43 |
20:43 |
Incoming video call |
(~1:30) |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:45 |
20:45 |
Received message |
Please delete this message when you get it. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:46 |
20:46 |
Sent message |
I can only delete messages I send |
NO |
NO |
NO |
NO |
NO |
NO |
|
24/04/2023 |
16:47 |
20:47 |
Received message |
Then delete that one. |
YES |
YES |
NO |
YES |
NO |
YES |
|
24/04/2023 |
16:48 |
20:48 |
Deleted message |
(Message sent at 16:46) |
NO |
NO |
NO |
NO |
NO |
NO |
|
24/04/2023 |
16:49 |
20:49 |
Sent message |
Deleted. |
YES |
YES |
NO |
YES |
NO |
YES |
The overall results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
YES |
YES |
YES |
NO |
YES |
|
Contacts |
NO |
YES |
YES |
YES |
NO |
NO |
|
Messages |
YES |
YES |
NO |
YES |
NO |
YES |
|
Deleted message |
NO |
NO |
NO |
NO |
NO |
NO |
|
Calls |
YES |
YES |
NO |
YES |
NO |
YES |
|
Servers |
NO |
NO |
YES |
NO |
NO |
NO |
|
Cache |
NO |
NO |
YES |
YES |
NO |
NO |
Facebook Messenger
Relevant information for this application is
stored in these files:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/Library/Application Support/lightspeed-userDatabases/<User_ID>.db
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Preferences/com.facebook.Messenger.plist
Direct parsing of this application is supported
by all tested tools.
Some differences were found in parsing capabilities. The deleted message was
recovered from the SQLite database by most of the tools.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
Type |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
25/04/2023 |
13:47 |
17:47 |
Sent message |
You here? |
Normal chat |
NO |
NO |
NO |
NO |
NO |
NO |
|
25/04/2023 |
13:48 |
17:48 |
Received message |
You know it |
Normal chat |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
25/04/2023 |
13:49 |
17:49 |
Sent message |
Awesome. Let’s make this quick, shall we? We also
have secure chat to do. |
Normal chat |
NO |
NO |
NO |
NO |
NO |
NO |
|
25/04/2023 |
13:51 |
17:51 |
Received message |
Sounds good to me. Do you even have any pictures
to send? Lol. |
Normal chat |
YES |
YES |
NO |
YES |
YES |
Notifications |
|
25/04/2023 |
13:52 |
17:52 |
Sent message |
Not much. I need to download a few. |
Normal chat |
YES |
YES |
NO |
YES |
YES |
NO |
|
25/04/2023 |
13:53 |
17:53 |
Received message |
I figured as much. Imgur is a good app. |
Normal chat |
YES |
YES |
NO |
YES |
YES |
Notifications |
|
25/04/2023 |
13:54 |
17:54 |
Sent message |
I’ll look at it later. Here comes a picture. |
Normal chat |
YES |
YES |
NO |
YES |
YES |
NO |
|
25/04/2023 |
13:56 |
17:56 |
Sent picture |
YouTuber |
Normal chat |
NO |
YES |
NO |
YES |
YES |
NO |
|
25/04/2023 |
13:57 |
17:57 |
Received message |
Nice. I’ll send one. Give me a moment. |
Normal chat |
YES |
YES |
NO |
YES |
YES |
Notifications |
|
25/04/2023 |
13:59 |
17:59 |
Received picture |
Free tacos |
Normal chat |
NO |
YES |
NO |
YES |
NO |
NO |
|
25/04/2023 |
14:01 |
18:01 |
Sent message |
Lol. I will call you in a minute. |
Normal chat |
YES |
YES |
NO |
YES |
YES |
NO |
|
25/04/2023 |
14:01 |
18:01 |
Other party liked message |
(Message sent 14:01 - heart emoji) |
Normal chat |
NO |
NO |
NO |
NO |
NO |
NO |
|
25/04/2023 |
14:02 |
18:02 |
Outgoing audio call |
Call failed |
Normal chat |
YES |
YES |
NO |
YES |
YES |
NO |
|
25/04/2023 |
14:02 |
18:02 |
Incoming audio call |
(~1:20) |
Normal chat |
YES |
YES |
NO |
YES |
YES |
NO |
|
25/04/2023 |
14:04 |
18:04 |
Sent message |
Ok. I’ll try to call you again. Lol. |
Normal chat |
YES |
YES |
YES |
YES |
YES |
YES |
|
25/04/2023 |
14:05 |
18:05 |
Outgoing audio call |
(~1:30) |
Normal chat |
YES |
YES |
NO |
YES |
YES |
NO |
|
25/04/2023 |
14:07 |
18:07 |
Received message |
Here comes a video call. |
Normal chat |
YES |
YES |
YES |
YES |
YES |
YES |
|
25/04/2023 |
14:08 |
18:08 |
Incoming video call |
Call failed |
Normal chat |
YES |
YES |
NO |
YES |
YES |
NO |
|
25/04/2023 |
14:08 |
18:08 |
Outgoing video call |
(~1:30) |
Normal chat |
YES |
YES |
NO |
YES |
YES |
NO |
|
25/04/2023 |
14:10 |
18:10 |
Sent message |
Want to try again? |
Normal chat |
YES |
YES |
YES |
YES |
YES |
YES |
|
25/04/2023 |
14:12 |
18:12 |
Incoming video call |
(~1:30) |
Normal chat |
YES |
YES |
NO |
YES |
YES |
NO |
|
25/04/2023 |
14:14 |
18:14 |
Received message |
I’m over in secure chat now. |
Secure chat |
Notifications |
YES |
NO |
Notifications |
NO |
Notifications |
|
25/04/2023 |
14:15 |
18:15 |
Sent message |
Same. Send me a picture please. |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
14:16 |
18:16 |
Received picture |
A criminal |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
14:18 |
18:18 |
Sent message |
Nice. I will send you one. Hang on. |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
14:19 |
18:19 |
Sent picture |
Task failed successfully |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
14:20 |
18:20 |
Received message |
I will audio call you |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
14:21 |
18:21 |
Liked message |
(Message received at 14:20 – heart emoji) |
Secure chat |
NO |
NO |
NO |
NO |
NO |
NO |
|
25/04/2023 |
14:22 |
18:22 |
Incoming audio call |
(~1:40) |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
14:24 |
18:24 |
Sent message |
I will audio call you now. |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
14:25 |
18:25 |
Outgoing audio call |
(~1:35) |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
14:28 |
18:28 |
Received message |
I will video call you after I get back. |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
17:04 |
21:04 |
Incoming video call |
(~1:30) |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
17:06 |
21:06 |
Sent message |
I will video call you in a minute. |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
17:07 |
21:07 |
Outgoing video call |
(~1:30) |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
17:09 |
21:09 |
Sent message |
I will delete this message momentarily. |
Secure chat |
NO |
NO |
NO |
NO |
NO |
NO |
|
25/04/2023 |
17:10 |
21:10 |
Unsent message |
(message sent at 17:09) |
Secure chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
25/04/2023 |
17:11 |
21:11 |
Received message |
Please delete this message when you get it. |
Normal chat |
YES |
YES |
NO |
YES |
YES |
Notifications |
|
25/04/2023 |
17:12 |
21:12 |
Removed message |
(message received at 17:11) |
Normal chat |
YES |
YES |
YES |
YES |
YES |
NO |
|
25/04/2023 |
17:13 |
21:13 |
Sent message |
I removed it. |
Normal chat |
YES |
YES |
YES |
YES |
YES |
YES |
|
25/04/2023 |
11:36 |
15:36 |
Sent static location |
|
Normal chat |
YES |
YES |
YES |
YES |
NO |
NO |
|
17/05/2023 |
11:43 |
15:43 |
Received static location |
|
Normal chat |
YES |
YES |
YES |
YES |
NO |
NO |
|
17/05/2023 |
11:48 |
15:48 |
Started sending dynamic location |
|
Normal chat |
YES |
YES |
YES |
YES |
NO |
YES |
|
17/05/2023 |
11:53 |
15:53 |
Stopped sending dynamic location |
|
Normal chat |
YES |
YES |
YES |
YES |
NO |
NO |
|
17/05/2023 |
11:56 |
15:56 |
Started receiving dynamic location |
|
Normal chat |
YES |
YES |
YES |
YES |
NO |
YES |
|
17/05/2023 |
12:01 |
16:01 |
Stopped sending dynamic location |
|
Normal chat |
YES |
YES |
YES |
YES |
NO |
NO |
The overall results for each category and tool
are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
YES |
YES |
YES |
NO |
NO |
|
Contacts |
NO |
YES |
YES |
YES |
YES |
NO |
|
Chat |
YES |
YES |
YES |
YES |
YES |
NO |
|
Secure Chat |
NO |
YES |
NO |
NO |
NO |
NO |
|
Deleted message |
YES |
YES |
NO |
YES |
YES |
NO |
|
Calls |
YES |
YES |
NO |
YES |
NO |
YES |
|
Static Location |
YES |
YES |
YES |
YES |
NO |
NO |
|
Dynamic Location |
YES |
YES |
YES |
YES |
NO |
YES |
Google Chat
Relevant information for this application is
stored in an SQLite database:
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/user_accounts/<USER_ID>/dynamite.db
Direct parsing of this application is supported
by OXYGEN and BELKASOFT. AXIOM, PA, XAMN, and iLEAPP were able to parse some incoming messages
from iOS notifications.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
26/04/2023 |
12:28 |
16:28 |
Received message |
In Google Chat. You here? |
Notifications |
Notifications |
YES |
Notifications |
YES |
Notifications |
|
26/04/2023 |
12:30 |
16:30 |
Sent message |
I am. My better is dying. This poor phone |
NO |
NO |
YES |
NO |
YES |
NO |
|
26/04/2023 |
12:31 |
16:31 |
Sent message |
My battery is dying*** |
NO |
NO |
YES |
NO |
YES |
NO |
|
26/04/2023 |
12:32 |
16:32 |
Received message |
Lol. I figured that is what you meant. |
Notifications |
Notifications |
YES |
Notifications |
YES |
Notifications |
|
26/04/2023 |
12:33 |
16:33 |
Sent message |
Let’s make this quick. Here comes a picture |
NO |
NO |
YES |
NO |
YES |
NO |
|
26/04/2023 |
12:37 |
16:37 |
Sent picture |
Your PC |
NO |
NO |
YES |
NO |
YES |
NO |
|
26/04/2023 |
12:38 |
16:38 |
Other party reacted |
(ROFL emoji) |
NO |
NO |
YES |
NO |
YES |
NO |
|
26/04/2023 |
12:39 |
16:39 |
Received message |
Got it. I’ll send you one |
Notifications |
Notifications |
YES |
Notifications |
YES |
Notifications |
|
26/04/2023 |
12:40 |
16:40 |
Received picture |
Team of 1980 |
Notifications |
Notifications |
NO |
Notifications |
YES |
Notifications |
|
26/04/2023 |
12:42 |
16:42 |
Sent message |
I’ll make a new group. Give me a few minutes |
NO |
NO |
YES |
NO |
YES |
NO |
|
26/04/2023 |
12:44 |
16:44 |
Created space |
iOS 15 Test Space / added DFIR Two to space |
NO |
NO |
YES |
NO |
YES |
NO |
|
26/04/2023 |
12:45 |
16:45 |
Sent message |
You here? |
NO |
NO |
YES |
NO |
YES |
NO |
|
26/04/2023 |
12:46 |
16:46 |
Received message |
I am. How’s the battery doing? |
Notifications |
Notifications |
YES |
Notifications |
YES |
Notifications |
|
26/04/2023 |
12:47 |
16:47 |
Sent message |
Not great. (Smiley face emoji) |
NO |
NO |
YES |
NO |
YES |
NO |
|
26/04/2023 |
12:49 |
16:49 |
Received message |
No calls on this app? |
Notifications |
Notifications |
YES |
Notifications |
YES |
Notifications |
|
26/04/2023 |
12:50 |
16:50 |
Sent message |
Doesn’t appear so. I’ll send a picture. Hang on. |
NO |
NO |
YES |
NO |
YES |
NO |
|
26/04/2023 |
12:52 |
16:52 |
Sent picture |
Chickens |
NO |
NO |
NO |
NO |
YES |
NO |
|
26/04/2023 |
12:53 |
16:53 |
Received message |
Got it. I’ll send one now |
Notifications |
Notifications |
YES |
Notifications |
YES |
Notifications |
|
26/04/2023 |
12:54 |
16:54 |
Received picture |
The shower |
Notifications |
Notifications |
NO |
Notifications |
YES |
Notifications |
The overall results for each category and tool
are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
YES |
NO |
YES |
NO |
|
Contacts |
NO |
NO |
YES |
NO |
YES |
NO |
|
Groups Chat Info |
NO |
NO |
YES |
NO |
YES |
NO |
|
Messages |
Notifications |
Notifications |
YES |
Notifications |
YES |
Notifications |
|
Cache |
NO |
NO |
YES |
NO |
NO |
NO |
|
Message reactions |
NO |
NO |
YES |
NO |
NO |
NO |
Google Meet
Relevant information for this application is
stored in these files:
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Application Support/DataStore
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Preferences/com.google.Tachyon.plist
Direct parsing of this application is supported
by AXIOM, OXYGEN, XAMN, and iLEAPP. PA parsed some calls from the native call history.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
26/04/2023 |
11:11 |
15:11 |
Outgoing video call |
(1:20) |
YES |
YES |
YES |
YES |
NO |
YES |
|
26/04/2023 |
11:14 |
15:14 |
Incoming video call |
(1:31) |
YES |
YES |
YES |
YES |
NO |
YES |
|
26/04/2023 |
11:17 |
15:17 |
Outgoing audio call |
(1:30) |
YES |
YES |
YES |
YES |
NO |
YES |
|
26/04/2023 |
11:20 |
15:20 |
Incoming audio call |
(1:35) |
YES |
YES |
YES |
YES |
NO |
YES |
|
26/04/2023 |
11:23 |
15:23 |
Received note |
I am sending you this note. |
YES |
NO |
YES |
YES |
NO |
YES |
|
26/04/2023 |
11:27 |
15:27 |
Sent note |
Note received. Here is your note. |
YES |
NO |
YES |
YES |
NO |
YES |
The overall results for each category and tool
are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
YES |
NO |
YES |
YES |
NO |
NO |
|
Contacts |
YES |
NO |
YES |
YES |
NO |
YES |
|
Calls |
YES |
YES |
YES |
YES |
NO |
YES |
|
Notes |
YES |
NO |
YES |
YES |
NO |
YES |
Google Voice
Relevant information for this application is
stored in these files:
- /private/var/mobile/Containers/Shared/AppGroup/<APP_GUID>/voiceClientSettings
- /private/var/mobile/Containers/Shared/AppGroup/<APP_GUID>/threadingStore.sqlite
Direct parsing of this application is only
supported by OXYGEN.
AXIOM, PA, XAMN, and iLEAPP extracted some incoming messages from iOS
notifications, including the deleted one.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
05/05/2023 |
13:19 |
17:19 |
Obtained new number |
|
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
14:13 |
18:13 |
Sent message |
Are you here? |
NO |
NO |
YES |
NO |
NO |
NO |
|
05/05/2023 |
14:14 |
18:14 |
Received message |
I am. What number is this? |
Notifications |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
05/05/2023 |
14:15 |
18:15 |
Sent message |
Google Voice. It should show up as Wrightsville
Beach. |
NO |
NO |
YES |
NO |
NO |
NO |
|
05/05/2023 |
14:16 |
18:16 |
Received message |
It’s an 839 number. Not sure if that’s WB. Things
have changed. |
Notifications |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
05/05/2023 |
14:17 |
18:17 |
Sent message |
Good point. Number portability is a pain |
NO |
NO |
YES |
NO |
NO |
NO |
|
05/05/2023 |
14:19 |
18:19 |
Received message |
Not much you can do. Oh well. (Man shrugging
emoji) |
Notifications |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
05/05/2023 |
14:20 |
18:20 |
Sent message |
You are correct. Want to send me a picture? |
NO |
NO |
YES |
NO |
NO |
NO |
|
05/05/2023 |
14:21 |
18:21 |
Received message |
Sure. Give me a minute to find one. |
Notifications |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
05/05/2023 |
14:22 |
18:22 |
Received picture |
I is silent |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
14:24 |
18:24 |
Sent message |
Lol. That’s sooo true. Hang on and I’ll send one. |
NO |
NO |
YES |
NO |
NO |
NO |
|
05/05/2023 |
14:26 |
18:26 |
Sent picture |
Missed it by that much |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
14:27 |
18:27 |
Received message |
We can do calls when you get back. |
Notifications |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
05/05/2023 |
16:09 |
20:09 |
Sent message |
I’m back. I’ll call you momentarily. |
NO |
NO |
YES |
NO |
NO |
NO |
|
05/05/2023 |
16:11 |
20:11 |
Outgoing call |
(call to 504-302-3074) (1:35) |
NO |
NO |
YES |
NO |
NO |
NO |
|
05/05/2023 |
16:14 |
20:14 |
Received message |
Great. Now I will call you. |
Notifications |
Notifications |
YES |
Notifications |
NO |
Notifications |
|
05/05/2023 |
16:16 |
20:16 |
Incoming call |
(0:20) |
NO |
NO |
YES |
NO |
NO |
NO |
|
05/05/2023 |
16:18 |
20:18 |
Received message |
Here is your bad message. Delete it when you get
a chance |
Notifications |
Notifications |
Notifications |
Notifications |
NO |
Notifications |
|
05/05/2023 |
16:19 |
20:19 |
Deleted message |
(Message received at 16:18) |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
16:21 |
20:21 |
Sent message |
It’s gone. (Smiley face emoji) |
NO |
NO |
YES |
NO |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
YES |
NO |
NO |
NO |
|
Contacts |
NO |
NO |
YES |
NO |
NO |
NO |
|
Messages |
NO |
NO |
YES |
Notifications |
NO |
Notifications |
|
Deleted message |
Notifications |
Notifications |
Notifications |
Notifications |
NO |
Notifications |
|
Attechments |
NO |
NO |
Photos |
NO |
NO |
NO |
|
Deleted message |
Notifications |
Notifications |
Notifications |
Notifications |
NO |
Notifications |
|
Cache |
NO |
NO |
NO |
NO |
NO |
NO |
GroupMe
Relevant information for this application is
stored in these files:
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Preferences/com.groupme.iphone-app.plist
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/GroupMe.sqlite
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/com.groupme.iphone-app/Cache.db
Direct parsing of this application is supported
by AXIOM, PA, OXYGEN, and XAMN. iLEAPP parsed some incoming messages from iOS notifications. BELKASOFT officially supports this app, but
it only parsed older messages and not messages sent/received in 2023. The
deleted message was not recovered by any of the tested tools.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
26/04/2023 |
11:42 |
15:42 |
Sent message |
You here? |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
11:44 |
15:44 |
Received message |
I totally am! What’s up?! |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
26/04/2023 |
11:48 |
15:48 |
Sent message |
Nothing much. No new TV shows this week,
unfortunately |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
11:49 |
15:49 |
Received message |
Yeah. It’s getting into the slow season. Strange
New Worlds is coming, though. |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
26/04/2023 |
11:50 |
15:50 |
Sent message |
In what, June? |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
11:51 |
15:51 |
Received message |
June 15th. It will be here before you know it |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
26/04/2023 |
11:52 |
15:52 |
Sent message |
True. Here comes a picture. |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
11:53 |
15:53 |
Sent picture |
Storm Trooper selfie |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
11:54 |
15:54 |
Other party liked picture |
(Picture sent at 11:53) |
NO |
NO |
YES |
NO |
NO |
Notifications |
|
26/04/2023 |
11:55 |
15:55 |
Received message |
Nice. I’ll send one. Just a moment |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
26/04/2023 |
11:57 |
15:57 |
Received picture |
Is this your card? |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
26/04/2023 |
11:58 |
15:58 |
Sent message |
Move over to DM? |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
11:59 |
15:59 |
Received message |
Sure. |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
26/04/2023 |
12:00 |
16:00 |
Received message |
Here. It looks like I can only delete messages I
sent. |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
26/04/2023 |
12:01 |
16:01 |
Sent message |
Same for me. I can hide your messages |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
12:02 |
16:02 |
Received message |
Hide this message. |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
26/04/2023 |
12:03 |
16:03 |
Hid message |
(Message received at 12:02) |
NO |
NO |
YES |
YES |
NO |
NO |
|
26/04/2023 |
12:04 |
16:04 |
Sent message |
Done |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
12:05 |
16:05 |
Received message |
I’m sending you a picture |
NO |
NO |
YES |
YES |
NO |
NO |
|
26/04/2023 |
12:06 |
16:06 |
Received picture |
Soundcloud |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
26/04/2023 |
12:08 |
16:08 |
Liked picture |
(Picture received at 12:06) |
NO |
NO |
YES |
NO |
NO |
NO |
|
26/04/2023 |
12:09 |
16:09 |
Sent message |
Nice. I’ll send one. Standby. |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
12:12 |
16:12 |
Sent picture |
New car |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
12:16 |
16:16 |
Sent message |
Got it. I am going to delete this message. |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
12:17 |
16:17 |
Delted message |
(Message sent at 12:16) |
NO |
NO |
NO |
NO |
NO |
NO |
|
26/04/2023 |
12:18 |
16:18 |
Sent message |
I am going to delete this message |
YES |
YES |
YES |
YES |
NO |
NO |
|
26/04/2023 |
12:19 |
16:19 |
Delted message |
(Message sent at 12:18) |
NO |
NO |
NO |
NO |
NO |
NO |
|
17/05/2023 |
08:48 |
12:48 |
Sent static location |
|
YES |
YES |
YES |
YES |
YES |
NO |
|
17/05/2023 |
08:52 |
12:52 |
Received static location |
|
YES |
YES |
YES |
YES |
YES |
Notifications |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
YES |
YES |
YES |
YES |
NO |
NO |
|
Contacts |
YES |
YES |
YES |
NO |
YES |
YES |
|
Groups |
YES |
YES |
YES |
YES |
YES |
NO |
|
Messages |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
Hidden Messages |
YES |
YES |
YES |
YES |
NO |
Notifications |
|
Deleted Messages |
YES |
YES |
YES |
YES |
NO |
NO |
|
Message Likes |
NO |
NO |
YES |
NO |
NO |
NO |
|
Attachments |
YES |
YES |
YES |
YES |
NO |
NO |
|
Static location |
YES |
YES |
YES |
YES |
YES |
Notifications |
imoHD
Relevant
information for this application is stored in an SQLite database:
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/IMODb2.sqlite
Direct parsing of this application is supported
by AXIOM, BELKASOFT, and iLEAPP. PA and XAMN parsed some incoming messages from iOS notifications. PA supports imo but not imoHD, support for
imoHD is coming. XAMN supports imoHD in version 7.8. BELKASOFT was the only
tool able to recover the deleted message from the database.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
26/04/2023 |
14:11 |
18:11 |
Received message |
Are you on imo? |
YES |
Notifications |
NO |
Notifications |
YES |
YES |
|
26/04/2023 |
14:12 |
18:12 |
Sent message |
I am. I cannot find my HAL avatar |
YES |
NO |
NO |
NO |
YES |
YES |
|
26/04/2023 |
14:14 |
18:14 |
Received message |
I have it. I can send it to you. |
YES |
Notifications |
NO |
Notifications |
YES |
YES |
|
26/04/2023 |
14:15 |
18:15 |
Sent message |
Please and thank you. |
YES |
NO |
NO |
NO |
YES |
YES |
|
26/04/2023 |
14:16 |
18:16 |
Received message |
HAL |
YES |
Notifications |
NO |
Notifications |
NO |
YES |
|
26/04/2023 |
14:18 |
18:18 |
Changed avatar picture and added to story |
HAL |
NO |
NO |
NO |
NO |
NO |
NO |
|
26/04/2023 |
14:19 |
18:19 |
Sent message |
How do I look? |
YES |
NO |
NO |
NO |
YES |
YES |
|
26/04/2023 |
14:20 |
18:20 |
Received message |
Like HAL |
YES |
NO |
NO |
NO |
YES |
YES |
|
27/04/2023 |
13:02 |
17:02 |
Sent message |
Can I audio call you? |
YES |
NO |
NO |
NO |
YES |
YES |
|
27/04/2023 |
13:03 |
17:03 |
Received message |
Sure. Whenever you’re ready. |
YES |
Notifications |
NO |
Notifications |
YES |
YES |
|
27/04/2023 |
13:04 |
17:04 |
Outgoing audio call |
(~0:20) |
NO |
NO |
NO |
NO |
NO |
NO |
|
27/04/2023 |
13:05 |
17:05 |
Received message |
How about I call you? |
YES |
Notifications |
NO |
Notifications |
YES |
YES |
|
27/04/2023 |
13:06 |
17:06 |
Sent message |
Sounds good. |
YES |
NO |
NO |
NO |
YES |
YES |
|
27/04/2023 |
13:07 |
17:07 |
Incoming audio call |
(~1:20) |
NO |
NO |
NO |
NO |
NO |
NO |
|
27/04/2023 |
13:10 |
17:10 |
Outgoing audio call |
(~1:29) |
NO |
NO |
NO |
NO |
NO |
NO |
|
27/04/2023 |
13:12 |
17:12 |
Received message |
I will video call you. |
YES |
Notifications |
NO |
Notifications |
YES |
YES |
|
27/04/2023 |
13:13 |
17:13 |
Incoming video call |
(~1:30) |
NO |
NO |
NO |
NO |
NO |
NO |
|
27/04/2023 |
13:16 |
17:16 |
Sent message |
My turn to video call |
YES |
NO |
NO |
NO |
YES |
YES |
|
27/04/2023 |
13:17 |
17:17 |
Outgoing video call |
(~1:40) |
NO |
NO |
NO |
NO |
NO |
NO |
|
27/04/2023 |
13:20 |
17:20 |
Received message |
Please delete this message when you get it |
Notifications |
Notifications |
NO |
Notifications |
YES |
YES |
|
27/04/2023 |
13:22 |
17:22 |
Deleted message |
(Message received at 13:20) |
YES |
NO |
NO |
NO |
NO |
YES |
|
27/04/2023 |
13:23 |
17:23 |
Sent message |
I deleted it. |
YES |
NO |
NO |
NO |
YES |
YES |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
NO |
NO |
NO |
NO |
|
Contacts |
YES |
NO |
NO |
NO |
YES |
YES |
|
Messages |
YES |
Notifications |
NO |
Notifications |
YES |
YES |
|
Deleted Message |
Notifications |
Notifications |
NO |
Notifications |
YES |
Notifications |
|
Calls |
NO |
NO |
NO |
NO |
NO |
NO |
|
Cache |
NO |
NO |
NO |
NO |
NO |
NO |
Relevant information for this application is
stored in these files:
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Application Support/DirectSQLiteDatabase/<User-ID>.db
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/com.burbn.instagram.IGImageCache/
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/Library/Preferences/group.com.burbn.instagram.plist
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/<User-ID>/user_bootstrap/shared_bootstraps.plist
Direct parsing of this application is supported
by all tested tools.
Most of the tools were able to correctly parse most of the relevant
information. The deleted message was not recovered by any of the tested
tools.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
27/04/2023 |
13:33 |
17:33 |
Received message |
You here? |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:34 |
17:34 |
Sent message |
I am. Long time no see. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:35 |
17:35 |
Received message |
Anything new? |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:36 |
17:36 |
Sent message |
Nope. Same as before. Battery is still dying like
crazy |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:37 |
17:37 |
Received message |
Understood. We can use my phone for the next image |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:38 |
17:38 |
Sent message |
Sounds good. I will send you a picture. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:39 |
17:39 |
Sent picture |
One ticket |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:40 |
17:40 |
Received message |
Got it. I’ll send you one now. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:41 |
17:41 |
Received picture |
Unpatched system |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:43 |
17:43 |
Sent message |
Received. I will audio call you now. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:44 |
17:44 |
Outgoing audio call |
(1:39) |
NO |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:46 |
17:46 |
Received message |
I will audio call you now. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:47 |
17:47 |
Incoming audio call |
(1:29) |
NO |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:49 |
17:49 |
Sent message |
I will video call you in a moment. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:50 |
17:50 |
Outgoing video call |
(1:39) |
NO |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:53 |
17:53 |
Received message |
Now I will video call you. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:54 |
17:54 |
Incoming video call |
(1:32) |
NO |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
13:56 |
17:56 |
Sent message |
We can only unsend messages here. I will unsend
this one in a moment. |
NO |
NO |
NO |
NO |
NO |
NO |
|
27/04/2023 |
13:57 |
17:57 |
Other party liked message |
(Message sent at 13:56) |
Notifications |
Notifications |
Notifications |
Notifications |
YES |
NO |
|
27/04/2023 |
13:58 |
17:58 |
Unsent message |
(Message sent at 13:56) |
NO |
NO |
NO |
NO |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
YES |
YES |
YES |
YES |
YES |
NO |
|
Posts |
YES |
NO |
YES |
NO |
NO |
NO |
|
Contacts |
YES |
YES |
YES |
YES |
YES |
NO |
|
Messages |
YES |
YES |
YES |
YES |
YES |
YES |
|
Deleted message |
NO |
NO |
NO |
NO |
NO |
NO |
|
Calls |
NO |
YES |
YES |
YES |
YES |
YES |
|
Cache |
YES |
NO |
YES |
YES |
YES |
NO |
kikMessenger
Relevant
information for this application is stored in these files:
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Preferences/com.kik.chat.plist
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/cores/private/<User-ID>/kik.sqlite
Direct
parsing of this application is supported by all tested tools. Most of the tools were able to
correctly parse most of the relevant information. The deleted message was
recovered from the SQLite database by AXIOM, PA, XAMN, and BELKASOFT.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
27/04/2023 |
14:02 |
18:02 |
Set profile photo |
HAL |
YES |
NO |
YES |
YES |
NO |
YES |
|
27/04/2023 |
14:06 |
18:06 |
Sent message |
Welcome to Kik. These ads are horrendous. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:08 |
18:08 |
Received message |
That’s how they keep the app free. Just not like
it used to be |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:09 |
18:09 |
Sent message |
True. Just don’t go back to the chat list window. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:10 |
18:10 |
Received message |
What happens if I do? |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:11 |
18:11 |
Sent message |
More ads. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:12 |
18:12 |
Received message |
Makes sense. How’s the battery? |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:13 |
18:13 |
Sent message |
Not great. At all. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:14 |
18:14 |
Received message |
Ok. We can make it quick. I’ll send you a picture |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:15 |
18:15 |
Received picture |
I own you |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:17 |
18:17 |
Sent message |
Got it. I’ll send you one. Let me look. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:18 |
18:18 |
Sent picture |
Work every day |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:19 |
18:19 |
Received message |
Got it. |
YES |
YES |
YES |
YES |
YES |
YES |
|
27/04/2023 |
14:20 |
18:20 |
Received message |
Please delete this message when you get it |
YES |
YES |
NO |
YES |
YES |
Notifications |
|
27/04/2023 |
14:21 |
18:21 |
Deleted message |
(Message received at 14:20) |
YES |
YES |
NO |
YES |
YES |
NO |
|
27/04/2023 |
14:22 |
18:22 |
Sent message |
It’s been deleted. |
YES |
YES |
YES |
YES |
YES |
YES |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
YES |
YES |
YES |
YES |
YES |
YES |
|
Contacts |
YES |
YES |
YES |
YES |
YES |
YES |
|
Messages |
YES |
YES |
YES |
YES |
YES |
YES |
|
Deleted message |
YES |
YES |
NO |
YES |
YES |
NO |
|
Attachments |
YES |
YES |
YES |
YES |
YES |
NO |
|
Cache |
NO |
NO |
YES |
YES |
NO |
NO |
Line
Relevant information for this application is
stored in these files:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/Application Support/PrivateStore/<User-ID>/Messages/Line.sqlite
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Preferences/jp.naver.line.plist
Direct parsing of this application is supported
by AXIOM, PA, OXYGEN, and BELKASOFT. All the tools correctly parsed relevant
information and all of them recovered the deleted message from the SQLite
database. iLEAPP parsed some incoming messages from iOS notifications.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
27/04/2023 |
14:29 |
18:29 |
Changed profile picture |
HAL |
NO |
NO |
NO |
YES |
NO |
NO |
|
27/04/2023 |
16:11 |
20:11 |
Received message |
I’m here. Just got back. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
27/04/2023 |
16:12 |
20:12 |
Sent message |
Same. Good thing, too. It started raining hard. |
YES |
YES |
YES |
YES |
YES |
NO |
|
27/04/2023 |
16:13 |
20:13 |
Received message |
We pulled in just as it started. I didn’t think
it would rain today. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
27/04/2023 |
16:18 |
20:18 |
Sent message |
What are you doing? |
YES |
YES |
YES |
YES |
YES |
NO |
|
27/04/2023 |
16:23 |
20:23 |
Received message |
Same thing as you. Generating data. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
08:41 |
12:41 |
Sent message |
Good morning! I will send a picture in a moment. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
08:43 |
12:43 |
Received message |
(Reply to message sent at 08:41) (Thumbs up emoji) |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
08:44 |
12:44 |
Sent picture |
Tax payers |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
08:45 |
12:45 |
Received message |
Got it. Nice. Let me find one to send to you. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
08:47 |
12:47 |
Received picture |
Hot pocket |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
08:49 |
12:49 |
Received message |
I will audio call you in just a moment |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
08:50 |
12:50 |
Incoming audio call |
(1:40) |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
08:52 |
12:52 |
Sent message |
Now I’ll audio call you |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
08:53 |
12:53 |
Outgoing audio call |
(1:30) |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
08:55 |
12:55 |
Received message |
Here comes a video call. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
08:57 |
12:57 |
Incoming video call |
(1:47) |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
08:59 |
12:59 |
Sent message |
My turn. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
09:00 |
13:00 |
Outgoing video call |
(1:23) |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
09:02 |
13:02 |
Received message |
Here is your bad message. Please delete it after
you get it. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
09:04 |
13:04 |
Deleted message |
(Message received at 09:02) |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
09:05 |
13:05 |
Sent message |
It has been deleted. |
YES |
YES |
YES |
YES |
YES |
NO |
|
17/05/2023 |
08:57 |
12:57 |
Sent static location |
|
YES |
YES |
YES |
YES |
YES |
NO |
|
17/05/2023 |
09:00 |
13:00 |
Received static location |
|
YES |
YES |
YES |
YES |
YES |
Notifications |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
YES |
YES |
YES |
YES |
YES |
NO |
|
Contacts |
YES |
YES |
YES |
YES |
YES |
NO |
|
Messages |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
Deleted message |
YES |
YES |
YES |
YES |
YES |
NO |
|
Calls |
YES |
YES |
YES |
YES |
YES |
NO |
|
Cache |
NO |
NO |
YES |
YES |
NO |
NO |
Mastodon
Relevant information for this application is
stored in an SQLite:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/Databases/shared.sqlite
Cache is
stored in this folder:
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/org.joinmastodon.app
Direct parsing of this app is only supported by
XAMN. AXIOM, PA,
and iLEAPP parsed some incoming messages from iOS notifications. The deleted
message was not recovered in the SQLite database, but it was still available in
iOS Notifications.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
05/05/2023 |
17:52 |
21:52 |
Received post |
You here? |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
05/05/2023 |
17:55 |
21:55 |
Sent post |
I am. My
keyboard got stuck on the emojis and could get out of it. |
NO |
NO |
NO |
YES |
NO |
NO |
|
05/05/2023 |
17:56 |
21:56 |
Received post |
Do you mean you couldn’t get out of it? |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
17:57 |
21:57 |
Sent post |
Lol. Yeah,
typo on my part (Smiley face emoji) |
NO |
NO |
NO |
YES |
NO |
NO |
|
05/05/2023 |
17:58 |
21:58 |
Received post |
No worries.
I think this might be it for the day.
Want to send me a picture. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
18:00 |
22:00 |
Sent post with picture |
Yes sir.
Here you go. (Picture: Jeffrey Dahmer) |
NO |
NO |
NO |
YES |
NO |
NO |
|
05/05/2023 |
18:01 |
22:01 |
Received post |
Ha!! I’ll
send one. Hang on. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
18:03 |
22:03 |
Received picture |
Baraoque |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
18:05 |
22:05 |
Received post |
Hey, here is your bad message. Make sure you delete it. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
18:07 |
22:07 |
Sent post |
I can’t. I
can only delete messages I send. I
will delete this one in a minute. |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
18:09 |
22:09 |
Deleted message |
(Post sent at 18:07) |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
18:10 |
22:10 |
Sent post |
It’s been deleted. |
NO |
NO |
NO |
YES |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
NO |
YES |
NO |
NO |
|
Contacts |
NO |
NO |
NO |
NO |
NO |
NO |
|
Messages |
NO |
NO |
NO |
YES |
NO |
Notifications |
|
Deleted message |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
Cache |
NO |
NO |
NO |
YES |
NO |
NO |
MeWe
Relevant information for this application is
stored in an SQLite database:
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/sgrouplesdb.sqlite
Direct parsing of this app is only supported by
XAMN. AXIOM, PA,
and iLEAPP parsed some incoming messages from iOS notifications. The deleted
message was not recovered in the SQLite database, but it was still available in
iOS Notifications.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
28/04/2023 |
09:10 |
13:10 |
Changed profile picture |
HAL |
NO |
NO |
NO |
NO |
NO |
NO |
|
28/04/2023 |
09:13 |
13:13 |
Sent message |
You here? |
NO |
NO |
NO |
YES |
NO |
NO |
|
28/04/2023 |
09:15 |
13:15 |
Received message |
I am! This one is limited IIRC. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
09:16 |
13:16 |
Sent message |
You are correct. You have to pay for extra
features like calling. |
NO |
NO |
NO |
YES |
NO |
NO |
|
28/04/2023 |
09:17 |
13:17 |
Received message |
So pictures and locations only? |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
09:18 |
13:18 |
Sent message |
You are correct. Speaking of which, here comes a
picture. |
NO |
NO |
NO |
YES |
NO |
NO |
|
28/04/2023 |
09:21 |
13:21 |
Sent picture |
Password reuse |
NO |
NO |
NO |
YES |
NO |
NO |
|
28/04/2023 |
09:23 |
13:23 |
Received message |
Lol. Let me find one to send you. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
09:24 |
13:24 |
Received picture |
Pooh missed Piglet |
NO |
NO |
NO |
YES |
NO |
NO |
|
28/04/2023 |
09:26 |
13:26 |
Sent message |
Lol. Ouch! |
NO |
NO |
NO |
YES |
NO |
NO |
|
28/04/2023 |
09:27 |
13:27 |
Received message |
I know I know. It’s funny, though. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
09:28 |
13:28 |
Sent message |
It so is. |
NO |
NO |
NO |
YES |
NO |
NO |
|
28/04/2023 |
09:29 |
13:29 |
Received message |
Please delete this bad message after you get it. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
28/04/2023 |
09:30 |
13:30 |
Deleted message |
(Message received at 09:29) |
NO |
NO |
NO |
NO |
NO |
NO |
|
28/04/2023 |
09:31 |
13:31 |
Sent message |
All good. I deleted it. |
NO |
NO |
NO |
YES |
NO |
NO |
|
17/05/2023 |
09:04 |
13:04 |
Sent static location |
|
NO |
NO |
NO |
YES |
NO |
NO |
|
17/05/2023 |
09:08 |
13:08 |
Received static location |
|
Notifications |
Notifications |
NO |
YES |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
NO |
YES |
NO |
NO |
|
Contacts |
NO |
NO |
NO |
YES |
NO |
NO |
|
Social Groups |
NO |
NO |
NO |
YES |
NO |
NO |
|
Polls |
NO |
NO |
NO |
YES |
NO |
NO |
|
Status updates |
NO |
NO |
NO |
YES |
NO |
NO |
|
Messages |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
Deleted message |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
Cache |
NO |
NO |
NO |
YES |
NO |
NO |
Session
Relevant information for this app is stored in
an SQLite database:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/database/Session.sqlite
Profile pictures and sent/received attachments
are stored at:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/ProfileAvatars
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/Attachments
The SQLite database is encrypted, and PA is the only tool with a decryption and parsing feature for this database.
XAMN, AXIOM, and iLEAPP parsed some incoming
messages from iOS notifications. The deleted message was not recovered by
any of the tested tools.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
01/05/2023 |
19:58 |
23:58 |
Set profile picture |
HAL |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:00 |
00:00 |
Scanned QR code |
|
NO |
NO |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:01 |
00:01 |
Sent message |
You here? |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:02 |
00:02 |
Received message |
Yep. What are you up to? |
Notifications |
YES |
NO |
Notifications |
NO |
Notifications |
|
01/05/2023 |
20:04 |
00:04 |
Sent message |
Not much. Watching Below Deck. You? |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:05 |
00:05 |
Received message |
Really? You’re still watching that? |
Notifications |
YES |
NO |
Notifications |
NO |
Notifications |
|
01/05/2023 |
20:06 |
00:06 |
Sent message |
Heck yeah! Good trashy TV. This is the one on the
sailboat. |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:08 |
00:08 |
Received message |
(Reply to message sent at 20:04) I’m not doing
anything, btw. Just flipping channels. |
Notifications |
YES |
NO |
Notifications |
NO |
Notifications |
|
01/05/2023 |
20:09 |
00:09 |
Sent message |
(Eye rolling emoji) You’re so lame. |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:11 |
00:11 |
Received message |
Whatever. I’ll send you a picture. |
Notifications |
YES |
NO |
Notifications |
NO |
Notifications |
|
01/05/2023 |
20:16 |
00:16 |
Received picture |
Acupuncture |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:18 |
00:18 |
Sent message |
Lol. I’ll send one. Give me a minute. |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:19 |
00:19 |
Sent picture |
Shell |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:21 |
00:21 |
Received system message |
(Media saved by DFIR Two.) |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:24 |
00:24 |
Received message |
Lol! That’s great. Please call me. |
Notifications |
YES |
NO |
Notifications |
NO |
Notifications |
|
01/05/2023 |
20:27 |
00:27 |
Outgoing audio call |
(1:35) |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:32 |
00:32 |
Sent message |
Your turn. |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:33 |
00:33 |
Incoming audio call |
(1:50) |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:36 |
00:36 |
Received message |
See if you can video call me. |
Notifications |
YES |
NO |
Notifications |
NO |
Notifications |
|
01/05/2023 |
20:40 |
00:40 |
Outgoing video call |
(1:50) |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:47 |
00:47 |
Received message |
I will video call you. |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:48 |
00:48 |
Incoming video call |
(1:40) |
Notifications |
YES |
NO |
Notifications |
NO |
Notifications |
|
01/05/2023 |
20:54 |
00:54 |
Received message |
You want to send me a “bad” message and then
delete it? |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:55 |
00:55 |
Sent message |
Sure. |
NO |
YES |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:56 |
00:56 |
Sent message |
Here is the bad message. I will delete it in a
moment. |
NO |
NO |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:58 |
00:58 |
Deleted message |
(Message sent at 20:56) |
NO |
NO |
NO |
NO |
NO |
NO |
|
01/05/2023 |
20:59 |
00:59 |
Received message |
I see you deleted it. |
NO |
YES |
NO |
NO |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
YES |
NO |
NO |
NO |
NO |
|
Contacts |
NO |
YES |
NO |
NO |
NO |
NO |
|
Messages |
Notifications |
YES |
NO |
Notifications |
NO |
Notifications |
|
Deleted Message |
NO |
NO |
NO |
NO |
NO |
NO |
|
Call |
NO |
YES |
NO |
NO |
NO |
|
|
Cache |
NO |
NO |
NO |
NO |
NO |
NO |
Signal
Relevant
information for this application is stored in an SQLite database:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/grdb/signal.sqlite
Profile
pictures and sent/received attachments are stored at:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/AvatarHistory
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/ProfileAvatars
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/Attachments
The SQLite database is encrypted, and
decryption is supported by AXIOM, PA, and XAMN. iLEAPP parsed some incoming messages from iOS
notifications. It’s important to mention that BELKSASOFT supports Signal
decryption on iOS devices (https://belkasoft.com/signal-decryption-with-belkasoft-x),
but in the tested case it was not able to read the keychain provided by the
extraction. The deleted message was not recovered from the SQLite database,
but it was still available in iOS notifications. PA also recovered a deleted
string from the SQLite database, without attribution (sender/recipient) but
still really useful.
Following is the comparison table with the details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
28/04/2023 |
11:38 |
15:38 |
Set profile picture |
HAL |
YES |
YES |
NO |
NO |
NO |
NO |
|
28/04/2023 |
11:39 |
15:39 |
Sent message |
I’m here! |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
11:40 |
15:40 |
Sent message |
Hello? |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
11:41 |
15:41 |
Received message |
I think you sent that message before I had my
phone setup. |
YES |
YES |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
11:42 |
15:42 |
Sent message |
My bad. |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
11:44 |
15:44 |
Received message |
No worries. I just didn’t get that first message.
No biggie. |
YES |
YES |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
11:46 |
15:46 |
Sent message |
Oh. Yeah, not that big of a deal. How’s the new
switch? |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
11:47 |
15:47 |
Received message |
It seems to be doing ok. Although, there isn’t a
lot of headroom with wattage. |
YES |
YES |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
11:48 |
15:48 |
Sent message |
An excuse to get a bigger one. (Smiley emoji) |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
11:50 |
15:50 |
Received message |
(Reply to message sent at 11:48) True. The new
rack can handle it. |
YES |
YES |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
11:51 |
15:51 |
Sent message |
I’ll send over a picture. |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
11:52 |
15:52 |
Sent picture |
Sorry I’m late |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
11:53 |
15:53 |
Received message |
Lol. Hang on. I’ll send one. |
YES |
YES |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
11:55 |
15:55 |
Received picture |
Poop |
YES |
YES |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
11:58 |
15:58 |
Sent message |
That’s great! I saved it. |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
11:59 |
15:59 |
Received message |
I’ll call you. Give me a second. |
YES |
YES |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
12:01 |
16:01 |
Incoming audio call |
(1:35) |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
12:03 |
16:03 |
Sent message |
I’ll go next |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
12:04 |
16:04 |
Outgoing audio call |
(1:40) |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
12:29 |
16:29 |
Received message |
I’ll video call you. |
YES |
YES |
NO |
YES |
NO |
Notifications |
|
28/04/2023 |
12:30 |
16:30 |
Incoming video call |
(1:40) |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
12:33 |
16:33 |
Sent message |
I’ll video call you now. |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
12:34 |
16:34 |
Outgoing video call |
(1:30) |
YES |
YES |
NO |
YES |
NO |
NO |
|
28/04/2023 |
12:37 |
16:37 |
Received message |
Here is your bad message. Please delete it when
you get a chance. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
28/04/2023 |
12:39 |
16:39 |
Deleted message |
(Message received at 12:37) |
NO |
NO |
NO |
NO |
NO |
NO |
|
28/04/2023 |
12:40 |
16:40 |
Sent message |
Got you covered. It’s gone. |
YES |
YES |
NO |
YES |
NO |
NO |
|
17/05/2023 |
09:32 |
13:32 |
Sent static location |
|
YES |
YES |
NO |
YES |
NO |
NO |
|
17/05/2023 |
09:34 |
13:34 |
Received static location |
|
YES |
YES |
NO |
YES |
NO |
Notifications |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
YES |
YES |
NO |
YES |
NO |
NO |
|
Contacts |
YES |
YES |
NO |
YES |
NO |
NO |
|
Messages |
YES |
YES |
NO |
YES |
NO |
Notifications |
|
Deleted message |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
Calls |
YES |
YES |
NO |
YES |
NO |
NO |
Silent Phone
Relevant information for this application is
stored in an SQLite database:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/com.silentcircle.SilentPhone/Chat/ChatMessages_cipher.db
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/com.silentcircle.SilentPhone/Preferences/preferences.plist
User account information is stored in a plist
file:
The SQLite database is encrypted and XAMN is
the only tool with a decryption and parsing feature for this database. So, direct parsing of this app is
only supported by XAMN.
AXIOM, PA, and iLEAPP parsed some incoming
messages from iOS notifications, but without text. The deleted message was
not recovered in the SQLite database and only the fact that it existed is
available in iOS notification (no text).
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
07/05/2023 |
10:25 |
14:25 |
Sent message |
Another “private” app. |
NO |
NO |
NO |
YES |
NO |
NO |
|
07/05/2023 |
10:26 |
14:26 |
Received message |
Yep. It’s getting old. How many more do we have? |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
07/05/2023 |
10:28 |
14:28 |
Sent message |
We are close on the 3rd party apps. We still have
native apps and the location stuff. |
NO |
NO |
NO |
YES |
NO |
NO |
|
07/05/2023 |
10:29 |
14:29 |
Received message |
Man, these things just keeping getting longer. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
07/05/2023 |
10:30 |
14:30 |
Sent message |
The more we learn about these devices, the more
test data that needs to be generated. That’s just how it is. |
NO |
NO |
NO |
YES |
NO |
NO |
|
07/05/2023 |
10:31 |
14:31 |
Received message |
I suppose. Here comes a picture. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
07/05/2023 |
10:32 |
14:32 |
Received picture |
Goats butter |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
07/05/2023 |
10:34 |
14:34 |
Sent message |
Nice. I’ll send one. Just a moment. |
NO |
NO |
NO |
YES |
NO |
NO |
|
07/05/2023 |
10:36 |
14:36 |
Sent picture |
Tax payers |
NO |
NO |
NO |
YES |
NO |
NO |
|
07/05/2023 |
10:38 |
14:38 |
Received message |
Haha!! Very nice. I’ll audio call you in a
minute. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
07/05/2023 |
10:40 |
14:40 |
Incoming audio call |
(1:30) |
NO |
NO |
NO |
YES |
NO |
NO |
|
07/05/2023 |
10:42 |
14:42 |
Sent message |
Got it. I’ll audio call you now. |
NO |
NO |
NO |
YES |
NO |
NO |
|
07/05/2023 |
10:43 |
14:43 |
Outgoing audio call |
(1:40) |
NO |
NO |
NO |
YES |
NO |
NO |
|
08/05/2023 |
11:42 |
15:42 |
Sent message |
Here comes your video call. |
NO |
NO |
NO |
YES |
NO |
NO |
|
08/05/2023 |
11:43 |
15:43 |
Outgoing video call |
(1:48) |
NO |
NO |
NO |
YES |
NO |
NO |
|
08/05/2023 |
11:45 |
15:45 |
Received message |
Got it. I’ll video call you in a minute. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
08/05/2023 |
11:46 |
15:46 |
Incoming video call |
(1:41) |
NO |
NO |
NO |
YES |
NO |
NO |
|
08/05/2023 |
11:50 |
15:50 |
Received message |
Here is your bad message. Please burn it and let
me know when you do. |
Notifications |
Notifications |
NO |
NO |
NO |
Notifications |
|
08/05/2023 |
11:51 |
15:51 |
Deleted message |
(Message received at 11:50) |
NO |
NO |
NO |
NO |
NO |
NO |
|
08/05/2023 |
11:52 |
15:52 |
Sent message |
You’re good. I burned it. |
NO |
NO |
NO |
YES |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
YES |
YES |
NO |
NO |
|
Contacts |
NO |
NO |
NO |
YES |
NO |
NO |
|
Messages |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
Deleted message |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
Calls |
NO |
NO |
NO |
YES |
NO |
NO |
|
Cache |
NO |
NO |
NO |
NO |
NO |
NO |
Skype
Relevant information for this application is
stored in an SQLite:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/s4l-live_.cid.<User-ID>.db
Direct parsing of this application is supported
by all tested tools.
Most of the tools were able to correctly parse most of the relevant
information. The deleted message was
recovered by AXIOM, PA, and BELKASOFT from the SQLite database.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
28/04/2023 |
12:48 |
16:48 |
Received message |
Did you make it over here? |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
12:49 |
16:49 |
Sent message |
I did! I’m watching DS9. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
12:52 |
16:52 |
Received message |
Nice. I need to, as well, considering Picard. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
12:54 |
16:54 |
Sent message |
That season was crazy. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
12:56 |
16:56 |
Received message |
Agreed. That is what Nemesis should have been. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
13:04 |
17:04 |
Sent message |
100%. Can you send me a picture? |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:05 |
17:05 |
Received message |
Sure. Give me a moment. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:08 |
17:08 |
Received picture |
4chan |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:10 |
17:10 |
Sent message |
Ha! I’ll send you one. Hang on. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:11 |
17:11 |
Sent picture |
Peter Cushing |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:13 |
17:13 |
Received message |
Never thought about that, but that is accurate. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
13:14 |
17:14 |
Sent message |
I’ll audio call you momentarily. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:16 |
17:16 |
Outgoing audio call |
(2:02) |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:19 |
17:19 |
Received message |
I’ll call you in a minute. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
13:20 |
17:20 |
Incoming audio call |
(1:36) |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:24 |
17:24 |
Sent message |
Here comes a video call. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
28/04/2023 |
13:25 |
17:25 |
Outgoing video call |
(1:41) |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:27 |
17:27 |
Received message |
Here comes your video call. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:28 |
17:28 |
Incoming video call |
(1:46) |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:31 |
17:31 |
Sent message |
I will remove this message in just a moment. |
YES |
YES |
YES |
YES |
YES |
NO |
|
28/04/2023 |
13:32 |
17:32 |
Removed message |
(Message sent at 13:31) |
YES |
YES |
NO |
NO |
YES |
NO |
|
17/05/2023 |
09:37 |
13:37 |
Received static location |
|
YES |
YES |
YES |
YES |
YES |
Notifications |
|
17/05/2023 |
09:39 |
13:39 |
Sent static location |
|
YES |
YES |
YES |
YES |
YES |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
YES |
YES |
YES |
YES |
NO |
|
Contacts |
YES |
YES |
YES |
YES |
YES |
NO |
|
Messages |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
Delete message |
YES |
YES |
NO |
NO |
YES |
NO |
|
Calls |
NO |
YES |
YES |
YES |
YES |
NO |
Snapchat
Relevant information for this application is
stored in these files and folders:
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/user.plist
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/user_scoped/<User-ID>/DocObjects/primary.docobjects
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/user_scoped/<User-ID>/arroyo/arroyo.db
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/user_scoped/<User-ID>/databases/memories_asset_repository.sqlite
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/gallery_data_object/1/<User-Id>/scdb-27.sqlite3
Direct parsing of this application is supported
by AXIOM, PA, OXYGEN, XAMN, BELKASOFT, and ArtEx. Most of the tools were able to correctly
parse most of the relevant information.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ARTEX |
ILEAPP |
|
20/05/2023 |
14:20 |
18:20 |
Sent message |
What’s up?? |
YES |
YES |
YES |
YES |
YES |
YES |
NO |
|
20/05/2023 |
14:23 |
18:23 |
Received message |
Nothing. At the park with the kid. You? |
YES |
YES |
YES |
YES |
YES |
YES |
NO |
|
20/05/2023 |
14:25 |
18:25 |
Sent message |
About the same. No kid, though. Gettin close on
this image. |
YES |
YES |
YES |
YES |
YES |
YES |
NO |
|
20/05/2023 |
14:30 |
18:30 |
Received message |
Nice. Are you doing 16 after? |
YES |
YES |
YES |
YES |
YES |
YES |
NO |
|
20/05/2023 |
14:31 |
18:31 |
Sent message |
Yep. I’ll be switching to the 11, though. This 8
has had it. |
YES |
YES |
YES |
YES |
YES |
YES |
NO |
|
20/05/2023 |
14:34 |
18:34 |
Received message |
Makes sense. Here comes a picture. |
YES |
YES |
YES |
YES |
YES |
YES |
NO |
|
20/05/2023 |
14:35 |
18:35 |
Unsaved video |
(Video from 2021-12-15) |
NO |
NO |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
14:37 |
18:37 |
Received picture |
Trash panda |
YES |
YES |
YES |
YES |
YES |
NO |
NO |
|
20/05/2023 |
14:39 |
18:39 |
Sent message |
Nice. I’ll send one. |
YES |
YES |
YES |
YES |
YES |
NO |
NO |
|
20/05/2023 |
14:40 |
18:40 |
Sent picture |
Wilmington |
YES |
YES |
YES |
YES |
YES |
NO |
NO |
|
20/05/2023 |
14:41 |
18:41 |
Other party saved picture to camera roll |
Wilmington |
YES |
YES |
YES |
YES |
YES |
NO |
NO |
|
20/05/2023 |
14:43 |
18:43 |
Took snap |
iPhone 11 (caption: Test phone two!) |
YES |
YES |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
14:44 |
18:44 |
Added snap to story & sent to DFIR Two |
|
YES |
YES |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
14:47 |
18:47 |
Other party took a screenshot |
|
NO |
NO |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
14:48 |
18:48 |
Received snap |
Notes |
YES |
YES |
NO |
Notifications |
NO |
NO |
Notifications |
|
20/05/2023 |
15:13 |
19:13 |
Saved snap in chat |
Notes |
YES |
YES |
NO |
NO |
NO |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ARTEX |
ILEAPP |
|
Account Information |
NO |
YES |
YES |
YES |
YES |
NO |
NO |
|
Contacts |
YES |
YES |
YES |
YES |
YES |
NO |
NO |
|
Messages |
YES |
YES |
YES |
YES |
YES |
YES |
NO |
|
Memories |
YES |
YES |
NO |
NO |
|
YES |
NO |
Telegram
Relevant information for this application is
stored in an SQLite:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/telegram-data/account-<Account_ID>/postbox/db_sqlite
Media are saved in the following folder:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/telegram-data/account-<Account_ID>/postbox/media
Direct parsing of this application is supported
by all tested tools.
Most of the tools were able to correctly parse most of the relevant
information. The deleted message was
not recovered by any of the tested tools.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
29/04/2023 |
15:58 |
19:58 |
Set profile picture |
HAL |
NO |
YES |
NO |
YES |
NO |
NO |
|
30/04/2023 |
10:38 |
14:38 |
Received message |
Good morning! |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
10:41 |
14:41 |
Sent message |
Good morning! Battery is mostly charged. Should
last about two hours. Lol. |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
10:43 |
14:43 |
Received message |
Ha! Sounds about right. What does the battery
health status ay? (sic) |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
10:44 |
14:44 |
Sent message |
86%, so not “service.” |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
10:46 |
14:46 |
Received message |
Well, something is up. I be that drop in the strawberry
field didn’t help. |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
10:47 |
14:47 |
Sent message |
No it did not. I’ll send you a picture in a
moment. |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
10:56 |
14:56 |
Sent picture |
I’m not dumb |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
10:57 |
14:57 |
Received message |
I also feel that. Lol. I’ll send you a picture
now. |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
10:59 |
14:59 |
Received picture |
Poop911 |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
11:08 |
15:08 |
Sent message |
I will audio call you in a minute. |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
11:09 |
15:09 |
Other party reacted to message |
(Message sent at 11:08) (Thumbs up emoji) |
NO |
NO |
NO |
NO |
NO |
NO |
|
30/04/2023 |
11:10 |
15:10 |
Received message |
(Reply to message sent at 11:08) Sounds good.
I’ll be here. |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
11:11 |
15:11 |
Outgoing audio call |
(1:35) |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
11:14 |
15:14 |
Received message |
Now I’ll audio call you. |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
11:15 |
15:15 |
Incoming audio call |
(1:40) |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
11:17 |
15:17 |
Sent message |
Video call incoming. |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
11:18 |
15:18 |
Outgoing video call |
(~1:30) |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
11:20 |
15:20 |
Received message |
Video call coming your way. |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
11:21 |
15:21 |
Incoming video call |
(~1:30) |
YES |
YES |
YES |
YES |
YES |
YES |
|
30/04/2023 |
11:23 |
15:23 |
Received message |
Here is your bad message. Delete it when you can. |
NO |
NO |
NO |
NO |
NO |
NO |
|
30/04/2023 |
11:24 |
15:24 |
Deleted message |
(Message received at 11:23) |
NO |
NO |
NO |
NO |
NO |
NO |
|
30/04/2023 |
11:25 |
15:25 |
Sent message |
Got you fam. It’s been trashed. |
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
09:42 |
13:42 |
Started receiving dynamic location |
|
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
09:47 |
13:47 |
Stopped receiving dynamic location |
|
YES |
YES |
YES |
NO |
YES |
NO |
|
17/05/2023 |
09:50 |
13:50 |
Received static location |
|
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
09:54 |
13:54 |
Sent static location |
|
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
10:00 |
14:00 |
Started sending dynamic location |
|
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
10:05 |
14:05 |
Stopped sending dynanic location |
|
YES |
YES |
YES |
NO |
YES |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
YES |
YES |
YES |
YES |
YES |
NO |
|
Contacts |
YES |
YES |
YES |
YES |
YES |
NO |
|
Messages |
YES |
YES |
YES |
YES |
YES |
YES |
|
Deleted message |
NO |
NO |
NO |
NO |
NO |
NO |
|
Calls |
YES |
YES |
YES |
YES |
YES |
YES |
|
Locations |
YES |
YES |
YES |
YES |
YES |
YES |
Threema
Relevant information for this application is
stored in an SQLite:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/ThreemaData.sqlite
Direct parsing of this application is supported
by PA, OXYGEN, and XAMN. Most of the tools were able to correctly parse most of the relevant
information. The deleted message was
recovered by OXYGEN and XAMN from the SQLite database.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
Date
Time (EDT)
Time (UTC)
Action
Message
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
30/04/2023
15:42
19:42
Set profile picture
HAL
NO
NO
YES
NO
NO
NO
30/04/2023
15:43
19:43
Sent message
What’s up?!
NO
YES
YES
YES
NO
NO
30/04/2023
15:44
19:44
Received message
Not much. Watching Bluey. Kid loves it.
NO
YES
YES
YES
NO
NO
30/04/2023
15:46
19:46
Sent message
Awesome. Which episode?
NO
YES
YES
YES
NO
NO
30/04/2023
15:47
19:47
Received message
The one where Chillie chases the kids and her dad
in the woods.
NO
YES
YES
YES
NO
NO
30/04/2023
15:49
19:49
Sent message
That’s a good one. My favorite is when Bandit
takes the kids to get Chinese takeout.
NO
YES
YES
YES
NO
NO
30/04/2023
15:50
19:50
Received message
That’s a good one. So is the date night episode.
NO
YES
YES
YES
NO
NO
30/04/2023
15:51
19:51
Sent message
Agreed. Send me a picture?
NO
YES
YES
YES
NO
NO
30/04/2023
15:52
19:52
Received message
(Reply to message sent at 15:51) Yep. Give me a
minute to find one.
NO
YES
YES
YES
NO
NO
30/04/2023
15:58
19:58
Received picture
Healthy Burgers
NO
YES
YES
YES
NO
NO
30/04/2023
16:00
20:00
Sent message
That’s great. I’ll send one.
NO
YES
YES
YES
NO
NO
30/04/2023
16:02
20:02
Sent picture
Food weapons
NO
YES
YES
YES
NO
NO
30/04/2023
16:04
20:04
Received message
I’ll call you in a minute.
NO
YES
YES
YES
NO
NO
30/04/2023
16:05
20:05
Reacted to message
(Message received at 16:04) (green thumbs up)
NO
NO
NO
NO
NO
NO
30/04/2023
16:06
20:06
Incoming audio call
(1:45)
NO
YES
YES
NO
NO
NO
30/04/2023
16:09
20:09
Sent message
My turn. I’ll audio call you.
NO
YES
YES
YES
NO
NO
30/04/2023
16:11
20:11
Outgoing audio call
(1:50)
NO
YES
YES
NO
NO
NO
30/04/2023
16:14
20:14
Received message
Let’s try video calls. I’ll go first.
Notifications
YES
YES
YES
NO
NO
30/04/2023
16:37
20:37
Incoming video call
(1:35)
NO
YES
YES
NO
NO
NO
30/04/2023
16:54
20:54
Sent message
My turn.
NO
YES
YES
YES
NO
NO
30/04/2023
16:55
20:55
Outgoing video call
(1:40)
NO
YES
YES
NO
NO
NO
30/04/2023
16:59
20:59
Received message
Please delete this message when you get it. I
don’t want anyone to see it.
NO
NO
YES
YES
NO
NO
30/04/2023
17:00
21:00
Deleted message
(Message received at 16:59)
NO
NO
YES
YES
NO
NO
30/04/2023
17:01
21:01
Sent message
It’s been handled (Smiley face emoji)
NO
YES
YES
YES
NO
NO
17/05/2023
10:09
14:09
Sent static location
NO
YES
YES
YES
NO
NO
17/05/2023
10:14
14:14
Received static location
NO
YES
YES
YES
NO
NO
The overall
results for each category and tool are shown in the following table.
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
Account Information
YES
YES
YES
YES
NO
NO
Contacts
NO
YES
YES
YES
NO
NO
Messages
NO
YES
YES
YES
NO
NO
Deleted message
NO
NO
YES
YES
NO
NO
Calls
NO
YES
YES
NO
NO
NO
Locations
NO
YES
YES
YES
NO
NO
Cache
NO
NO
NO
NO
NO
NO
TikTok
Relevant information for this application is
stored in these files:
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/AwemeIM.db
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Application
Support/ChatFiles/<User-Id>/db.sqlite
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/AWEStorage/UnifyStorage.sqlite
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Documents/kAWEPublishLocalVideoStorageFolder/
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/TTPlayerCache/
Direct parsing of this application is supported
by all tested tools.
Some differences were found in parsing capabilities.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
Date
Time (EDT)
Time (UTC)
Action
Message
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
17/05/2023
08:42
12:42
Added profile picture
HAL
NO
NO
NO
NO
NO
NO
20/05/2023
10:37
14:37
Sent message
Good morning. You around?
YES
YES
YES
YES
YES
YES
20/05/2023
10:38
14:38
Received message
(Reply to message sent at 10:37). I am. Good
morning!
YES
YES
YES
YES
YES
YES
20/05/2023
10:39
14:39
Liked message
(Message received at 10:38)
NO
NO
NO
NO
NO
NO
20/05/2023
10:44
14:44
Sent message
Awesome. Any plans for the day?
YES
YES
YES
YES
YES
YES
20/05/2023
10:45
14:45
Received message
Nope. You?
YES
YES
YES
YES
YES
YES
20/05/2023
10:46
14:46
Sent message
I am going to try to finish this image today.
Have a few map-related things to do.
YES
YES
YES
YES
YES
YES
20/05/2023
10:47
14:47
Received message
Did you finish Snapchat?
YES
YES
YES
YES
YES
YES
20/05/2023
10:48
14:48
Sent message
No. Also on the list.
YES
YES
YES
YES
YES
YES
20/05/2023
11:02
15:02
Received message
Better get to work then!
YES
YES
YES
YES
YES
YES
20/05/2023
11:03
15:03
Sent message
I know. (upside down smiley face emoji)
YES
YES
YES
YES
YES
YES
20/05/2023
14:03
18:03
Took picture
Coke & notes (with #work)
NO
NO
NO
NO
NO
NO
20/05/2023
14:04
18:04
Posted picture
(Taken at 14:03)
NO
NO
NO
NO
NO
NO
20/05/2023
14:06
18:06
Other party liked post
(Posted at 14:04)
Notifications
Notifications
NO
Notifications
NO
Notifications
20/05/2023
14:07
18:07
Other party commented on post
(Posted at 14:04) Shouldn’t you be off today?
NO
NO
NO
NO
NO
NO
20/05/2023
14:08
18:08
Replied to comment
(Comment received at 14:07) I should be. Lol.
Notifications
Notifications
NO
Notifications
NO
Notifications
20/05/2023
14:12
18:12
Liked other paty's post
NO
NO
NO
NO
NO
NO
20/05/2023
14:13
18:13
Commented on other paty's post
Don’t be lame. (ROFL emoji)
NO
NO
NO
NO
NO
NO
The overall
results for each category and tool are shown in the following table.
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
Account Information
YES
YES
NO
YES
YES
YES
Contacts
YES
YES
NO
NO
YES
YES
Groups
NO
NO
NO
YES
NO
NO
Messages
YES
YES
YES
YES
YES
YES
Media
YES
YES
YES
YES
YES
NO
Truth Social
Relevant information for this application is
stored in an SQLite:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/chat/v1/<User-ID>/ChatModel.sqlite
Attachments
are stored in this folder:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/chat/v1/<User-ID>/Attachments
None of
the compared tools had a parser for this application, so messages and contacts were not
parsed by any tool. Some received messages were recovered by AXIOM, PA, XAMN,
and iLEAPP in iOS notifications.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
Date
Time (EDT)
Time (UTC)
Action
Message
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
05/05/2023
16:52
20:52
Login
NO
NO
NO
NO
NO
NO
05/05/2023
16:53
20:53
Accepted friend request
(From @lizdehner)
NO
NO
NO
NO
NO
NO
05/05/2023
16:54
20:54
Changed message retention to 90 days
NO
NO
NO
NO
NO
NO
05/05/2023
16:59
20:59
Sent message
You here yet?
NO
NO
NO
NO
NO
NO
05/05/2023
17:00
21:00
Received message
I am! What are you doing?
Notifications
Notifications
NO
Notifications
NO
Notifications
05/05/2023
17:21
21:21
Sent message
Not much. Winding down for the day. Also need to
figure out dinner.
NO
NO
NO
NO
NO
NO
05/05/2023
17:22
21:22
Other party reacted to message
(Message sent at 17:21) (Thumb’s up emoji)
NO
NO
NO
NO
NO
NO
05/05/2023
17:23
21:23
Received message
I’m right there with you. I looked at the food
truck rodeo but there wasn’t anything I wanted.
Notifications
Notifications
NO
Notifications
NO
Notifications
05/05/2023
17:24
21:24
Sent message
Same here. I was leaning towards the waffle truck
but decided against it. Too crowded for waffles. Lol.
NO
NO
NO
NO
NO
NO
05/05/2023
17:26
21:26
Received message
Completely agree with the crowd. Too much of a
hassle.
Notifications
Notifications
NO
Notifications
NO
Notifications
05/05/2023
17:28
21:28
Sent message
Give me a minute and I’ll send you a picture.
NO
NO
NO
NO
NO
NO
05/05/2023
17:30
21:30
Sent picture
Furniture at 4 am
NO
NO
NO
NO
NO
NO
05/05/2023
17:31
21:31
Received message
I stayed in a hotel that had that type of chair.
It was creepy. I’ll send you one. Hang on.
Notifications
Notifications
NO
Notifications
NO
Notifications
05/05/2023
17:32
21:32
Received picture
Updating the firmware
NO
NO
NO
NO
NO
NO
05/05/2023
17:33
21:33
Saved picture
Updating the firmware
NO
NO
NO
NO
NO
NO
05/05/2023
17:34
21:34
Sent message
Ha! That’s great!
NO
NO
NO
NO
NO
NO
05/05/2023
17:35
21:35
Received message
Please delete this bad message when you get it.
And let me know.
Notifications
Notifications
NO
Notifications
NO
Notifications
05/05/2023
17:37
21:37
Deleted message
(Message received at 17:35)
NO
NO
NO
NO
NO
NO
05/05/2023
17:38
21:38
Sent message
It’s been deleted.
NO
NO
NO
NO
NO
NO
The overall
results for each category and tool are shown in the following table.
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
Account Information
NO
NO
NO
NO
NO
NO
Contacts
NO
NO
NO
NO
NO
NO
Messages
Notifications
Notifications
NO
Notifications
NO
Notifications
Deleted message
Notifications
Notifications
NO
Notifications
NO
Notifications
Cache
NO
NO
NO
NO
NO
NO
Twitter
Relevant information for this application is
stored in these files:
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/com.atebis.tweetie.direct-message.cache/<User-Id>
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/TSFModelCache.1/<User-Id>/modelCache.sqlite3
Direct parsing of this application is supported
by all tested tools.
Some differences were found in parsing capabilities. The deleted message was
not recovered from the SQLite database, but it was still available in iOS notifications.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
Date
Time (EDT)
Time (UTC)
Action
Message
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
02/05/2023
10:47
14:47
Sent message
Hey, are you here?
YES
YES
YES
YES
YES
NO
02/05/2023
10:48
14:48
Received message
I am. About time you came over.
YES
YES
YES
YES
YES
Notifications
02/05/2023
10:49
14:49
Sent message
Sorry. I have been a bit slow all morning.
YES
YES
YES
YES
YES
NO
02/05/2023
10:50
14:50
Received message
No worries. I was just kidding anyway. How’s the
morning been?
YES
YES
YES
YES
YES
Notifications
02/05/2023
10:51
14:51
Sent message
Not too bad. One meeting, one canceled meeting,
and one meeting that apparently wasn’t.
YES
YES
YES
YES
YES
NO
02/05/2023
10:53
14:53
Received message
Same same. I’ll add that I’m waiting for an
extraction to finish parsing.
YES
YES
YES
YES
YES
Notifications
02/05/2023
10:54
14:54
Sent message
Me, too. Mine is a do-over. PA got stuck the
first time.
YES
YES
YES
YES
YES
NO
02/05/2023
10:55
14:55
Other party reacted to message
(Message sent at 10:54) (Thumbs down emoji)
NO
Notifications
YES
Notifications
YES
Notifications
02/05/2023
10:56
14:56
Received message
Ugh. I hate it when that happens.
YES
YES
YES
YES
YES
Notifications
02/05/2023
10:57
14:57
Sent message
It happens. Here comes a picture.
YES
YES
YES
YES
YES
NO
02/05/2023
10:59
14:59
Sent picture
Sorry I’m late
YES
YES
YES
YES
YES
NO
02/05/2023
11:00
15:00
Received message
Ha! Appropriate. I’ll send one now.
YES
YES
YES
YES
YES
Notifications
02/05/2023
11:01
15:01
Received picture
Wizard of Oz
YES
YES
YES
YES
YES
NO
02/05/2023
11:03
15:03
Sent message
Lol.
YES
YES
YES
YES
YES
NO
02/05/2023
11:04
15:04
Received message
Here is your bad message. Please let me know when
you delete it.
Notifications
Notifications
NO
Notifications
NO
Notifications
02/05/2023
11:05
15:05
Deleted message
(Message received at 11:04)
NO
NO
NO
NO
NO
NO
02/05/2023
11:06
15:06
Sent message
Done. It’s been trashed (trash can emoji)
YES
YES
YES
YES
YES
NO
The overall
results for each category and tool are shown in the following table.
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
Account Information
NO
YES
YES
YES
YES
NO
Users
YES
YES
YES
YES
YES
NO
Messages
YES
YES
YES
YES
YES
Notifications
Deleted message
Notifications
Notifications
NO
Notifications
NO
Notifications
Cache
NO
NO
YES
YES
NO
NO
Viber
Relevant
information for this application is stored in two SQLite databases:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/com.viber/database/Contacts.data
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/com.viber/settings/Settings.data
Attachments
are saved in this path:
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/Attachments
Direct parsing of this application is supported
by all tested tools.
Most of the tools were able to correctly parse most of the relevant
information. The deleted message was
not recovered from the SQLite database, but it was still available in iOS
notifications.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
Date
Time (EDT)
Time (UTC)
Action
Message
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
02/05/2023
11:12
15:12
Sent message
You here?
YES
YES
YES
YES
YES
YES
02/05/2023
11:13
15:13
Received message
I am. Long time no see. Lol.
YES
YES
YES
YES
YES
YES
02/05/2023
11:15
15:15
Sent message
How’s the new switch?
YES
YES
YES
YES
YES
YES
02/05/2023
11:16
15:16
Received message
You mean the replacement for the new switch?
Good. A lot more headroom for the wattage.
YES
YES
YES
YES
YES
YES
02/05/2023
11:17
15:17
Liked message
(Message received at 11:16)
YES
YES
YES
YES
YES
YES
02/05/2023
11:18
15:18
Replied to message
(Message received at 11:16) How bad was it?
YES
YES
YES
YES
YES
YES
02/05/2023
11:19
15:19
Received message
I had one AP that would spike occasionally and
push it over the threshold.
YES
YES
YES
YES
YES
YES
02/05/2023
11:21
15:21
Sent message
What would happen?
YES
YES
YES
YES
YES
YES
02/05/2023
11:22
15:22
Received message
The AP would just reboot. Basically nothing would
connect to it because it wouldn’t stay up long enough.
YES
YES
YES
YES
YES
YES
02/05/2023
11:24
15:24
Sent message
That sucks. Want to send me a picture?
YES
YES
YES
YES
YES
YES
02/05/2023
11:25
15:25
Received message
Sure. Give me a minute to find one.
YES
YES
YES
YES
YES
YES
02/05/2023
11:26
15:26
Received picture
Try a reboot
YES
YES
YES
YES
YES
YES
02/05/2023
11:28
15:28
Sent message
Got it. I’ll send one in a moment.
YES
YES
YES
YES
YES
YES
02/05/2023
11:31
15:31
Sent picture
Clippy
YES
YES
YES
YES
YES
YES
02/05/2023
11:32
15:32
Received message
Nice, and possibly true. I’ll audio call you.
YES
YES
YES
YES
YES
YES
02/05/2023
11:33
15:33
Incoming audio call
(1:35)
YES
YES
YES
YES
YES
YES
02/05/2023
11:36
15:36
Sent message
My turn. I’ll audio call you.
YES
YES
YES
YES
YES
YES
02/05/2023
11:37
15:37
Outgoing audio call
(1:50)
YES
YES
YES
YES
YES
YES
02/05/2023
11:40
15:40
Received message
Here comes a video call.
YES
YES
YES
YES
YES
YES
02/05/2023
11:41
15:41
Incoming video call
(1:56)
YES
YES
YES
YES
YES
YES
02/05/2023
11:45
15:45
Sent message
Ok, here comes your video call.
YES
YES
YES
YES
YES
YES
02/05/2023
11:46
15:46
Outgoing video call
(1:35)
YES
YES
YES
YES
YES
YES
02/05/2023
11:49
15:49
Received message
Here is your bad message. Let me know when you
delete it.
Notifications
Notifications
NO
Notifications
NO
Notifications
02/05/2023
11:50
15:50
Deleted message
(Message received at 11:49)
NO
NO
NO
NO
NO
NO
02/05/2023
11:51
15:51
Sent message
It’s gone. You’re covered.
YES
YES
YES
YES
YES
YES
17/05/2023
10:17
14:17
Sent static location
YES
YES
YES
YES
YES
YES
17/05/2023
10:21
14:21
Received static location
YES
YES
YES
YES
YES
YES
The overall
results for each category and tool are shown in the following table.
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
Account Information
NO
YES
YES
YES
YES
YES
Contacts
NO
YES
YES
YES
YES
YES
Messages
YES
YES
YES
YES
YES
YES
Deleted message
Notifications
Notifications
NO
Notifications
NO
Notifications
Calls
YES
YES
YES
YES
YES
YES
Locations
YES
YES
YES
YES
YES
NO
WhatsApp
Relevant
information for this application is stored in these files and folders:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/Library/Preferences/group.net.whatsapp.WhatsApp.shared.plist
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/ContactsV2.sqlite
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/ChatStorage.sqlite
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/CallHistory.sqlite
Direct parsing of this application is supported
by all tested tools.
Most of the tools were able to correctly parse most of the relevant
information. The deleted message was
not recovered from the SQLite database, but it was still available in iOS notifications.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
Date
Time (EDT)
Time (UTC)
Action
Message
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
02/05/2023
11:55
15:55
Added profile picture
HAL
NO
YES
YES
YES
YES
NO
02/05/2023
11:56
15:56
Sent message
I’m here!
YES
YES
YES
YES
YES
YES
02/05/2023
11:57
15:57
Received message
Awesome. You had some chat history, eh?
YES
YES
YES
YES
YES
YES
02/05/2023
11:58
15:58
Sent message
Yep. I don’t recall setting it to back up, but
who knows.
YES
YES
YES
YES
YES
YES
02/05/2023
11:59
15:59
Received message
Makes sense with all the test data you generate.
YES
YES
YES
YES
YES
YES
02/05/2023
12:00
16:00
Reacted to message
(Message received at 11:59) (Thumbs up emoji)
NO
NO
NO
NO
NO
NO
02/05/2023
12:01
16:01
Replied to message
(Message received at 11:59) I do generate quite a
bit. I need to up my storage. A lot.
YES
YES
YES
YES
YES
YES
02/05/2023
12:02
16:02
Received message
QNAP is the way, my friend.
YES
YES
YES
YES
YES
YES
02/05/2023
12:03
16:03
Sent message
That’s what I keep hearing.
YES
YES
YES
YES
YES
YES
02/05/2023
12:04
16:04
Received message
You listen to good people then. Lol.
YES
YES
YES
YES
YES
YES
02/05/2023
12:05
16:05
Sent message
I do. Lol. I’ll send a picture. Just a moment.
YES
YES
YES
YES
YES
YES
02/05/2023
12:06
16:06
Sent picture
Mario Kart
YES
YES
YES
YES
YES
YES
02/05/2023
12:07
16:07
Received message
Accurate. Alright, I’ll send you one now.
YES
YES
YES
YES
YES
YES
02/05/2023
12:09
16:09
Received picture
Assault Cow
YES
YES
YES
YES
YES
YES
02/05/2023
12:11
16:11
Sent message
Nice. I’ll audio call you.
YES
YES
YES
YES
YES
YES
02/05/2023
12:12
16:12
Outgoing audio call
(1:35)
YES
YES
YES
YES
YES
NO
02/05/2023
12:14
16:14
Received message
Now it’s my turn to audio call you.
YES
YES
YES
YES
YES
YES
02/05/2023
12:15
16:15
Incoming audio call
(1:41)
YES
YES
YES
YES
YES
NO
02/05/2023
12:19
16:19
Sent message
Here comes a video call.
YES
YES
YES
YES
YES
YES
02/05/2023
12:20
16:20
Outgoing video call
(1:45)
YES
YES
YES
YES
YES
NO
02/05/2023
12:23
16:23
Received message
My turn. Here comes a video call.
YES
YES
YES
YES
YES
YES
02/05/2023
12:24
16:24
Incoming video call
(1:44)
YES
YES
YES
YES
YES
NO
02/05/2023
12:27
16:27
Received message
You can delete this message. Let me know when you
do.
Notifications
Notifications
NO
Notifications
NO
Notifications
02/05/2023
12:29
16:29
Deleted message
(Message received at 12:27)
NO
NO
NO
NO
NO
NO
02/05/2023
12:31
16:31
Sent message
Done. It’s gone. (Smiley face emoji)
YES
YES
YES
YES
YES
YES
17/05/2023
10:22
14:22
Started sending dynamic location
YES
YES
YES
YES
YES
YES
17/05/2023
10:27
14:27
Stopped sending dynamic location
YES
YES
YES
YES
YES
YES
17/05/2023
10:28
14:28
Started receiving dynamic location
YES
YES
YES
YES
YES
YES
17/05/2023
10:33
14:33
Stopped receiving dynamic location
YES
YES
YES
YES
YES
YES
17/05/2023
10:35
14:35
Sent static locaion
YES
YES
YES
YES
YES
YES
17/05/2023
10:36
14:36
Received static location
YES
YES
YES
YES
YES
YES
The overall
results for each category and tool are shown in the following table.
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
Account Information
YES
YES
YES
YES
YES
NO
Contacts
YES
YES
YES
YES
YES
YES
Groups
YES
YES
YES
YES
YES
NO
Messages
YES
YES
YES
YES
YES
YES
Deleted message
Notifications
Notifications
NO
Notifications
NO
Notifications
Calls
YES
YES
YES
YES
YES
NO
Dynamic Locations
YES
YES
YES
YES
YES
YES
Static Locations
YES
YES
YES
YES
YES
YES
WickrPro
Relevant information for this app is stored in
an SQLite database:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/wickrLocal.sqlite
Other relevant files and folders are:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/Logs
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Preferences/com.wickr.pro.prod.plist
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Logs
The SQLite database is encrypted, and PA is the
only tool with a decryption and parsing feature for this database. Oxygen parses the database and extracts messages and calls metadata, but without decryption of the content.
AXIOM and iLEAPP parsed some incoming messages from iOS notifications but
without text. The deleted message was not recovered by any of the tested
tools.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
Date
Time (EDT)
Time (UTC)
Action
Message
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
07/05/2023
08:55
12:55
Sent message
Good morning!
NO
YES
YES
NO
NO
NO
07/05/2023
08:56
12:56
Received message
Good morning to you as well. What are you doing?
Notifications
YES
YES
NO
NO
Notifications
07/05/2023
08:58
12:58
Sent message
Not much. Got up and cooked breakfast this
morning. Now everyone has run off.
NO
YES
YES
NO
NO
NO
07/05/2023
08:59
12:59
Received message
Makes sense. They’re all full and you’re not
useful anymore. Lol.
Notifications
YES
YES
NO
NO
Notifications
07/05/2023
09:03
13:03
Sent message
Ok, that’s fair. (Smiley face emoji)
NO
YES
YES
NO
NO
NO
07/05/2023
09:04
13:04
Received message
(Reply to message sent at 09:03) You’re such a
good sport.
Notifications
YES
YES
NO
NO
Notifications
07/05/2023
09:05
13:05
Sent message
I try. That’s all I can do.
NO
YES
YES
NO
NO
NO
07/05/2023
09:07
13:07
Received message
I have a good meme. Let me find where I put it
and I’ll send it to you.
Notifications
YES
YES
NO
NO
Notifications
07/05/2023
09:09
13:09
Reacted to message
(Message received at 09:07) (Thumbs up emoji)
NO
NO
NO
NO
NO
NO
07/05/2023
09:10
13:10
Received picture
East vs. West
Notifications
YES
YES
NO
NO
Notifications
07/05/2023
09:13
13:13
Sent message
Oh man, that’s awesome. Let me find one. Give me
a moment.
NO
YES
YES
NO
NO
NO
07/05/2023
09:14
13:14
Sent picture
Mediocretes
NO
YES
YES
NO
NO
NO
07/05/2023
09:18
13:18
Received message
Ha! Nice. I’ll audio call you.
Notifications
YES
YES
NO
NO
Notifications
07/05/2023
09:20
13:20
Incoming audio call
(1:45)
NO
YES
YES
NO
NO
NO
07/05/2023
09:23
13:23
Sent message
I’ll audio call you now.
NO
YES
YES
NO
NO
NO
07/05/2023
09:24
13:24
Outgoing audio call
(1:40)
NO
YES
YES
NO
NO
NO
07/05/2023
09:27
13:27
Received message
Here comes a video call.
Notifications
YES
YES
NO
NO
Notifications
07/05/2023
09:28
13:28
Incoming video call
(2:00)
NO
YES
YES
NO
NO
NO
07/05/2023
09:32
13:32
Sent message
Here comes your video call.
NO
YES
YES
NO
NO
NO
07/05/2023
09:33
13:33
Outgoing video call
(2:05)
NO
YES
YES
NO
NO
NO
07/05/2023
09:37
13:37
Sent message
I’ll see about creating a room. Give me a few
minutes.
NO
YES
YES
NO
NO
NO
07/05/2023
09:38
13:38
Created room
(Room name: iOS 15 Room)
NO
YES
YES
NO
NO
NO
07/05/2023
09:40
13:40
Sent message
You here?
NO
YES
YES
NO
NO
NO
07/05/2023
09:42
13:42
Received message
I am. Let’s make this quick. I’ll send you a
picture.
Notifications
YES
YES
NO
NO
Notifications
07/05/2023
09:44
13:44
Received picture
Eternal enemy
Notifications
YES
YES
NO
NO
Notifications
07/05/2023
09:46
13:46
Sent message
Got it. I’ll send you one now.
NO
YES
YES
NO
NO
NO
07/05/2023
09:49
13:49
Sent picture
Clicked on the link
NO
YES
YES
NO
NO
NO
07/05/2023
09:50
13:50
Received message
Nice. I’ll audio call you.
Notifications
YES
YES
NO
NO
Notifications
07/05/2023
09:51
13:51
Incoming meeting call
(1:43)
NO
YES
YES
NO
NO
NO
07/05/2023
09:55
13:55
Sent message
These just look like meetings. I’ll call you and
then we’ll call that part done.
NO
YES
YES
NO
NO
NO
07/05/2023
09:56
13:56
Outgoing meeting call
(1:40)
NO
YES
YES
NO
NO
NO
07/05/2023
09:59
13:59
Received message
Here is your bad message for the room. Please
delete it.
Notifications
Notifications
YES
NO
NO
Notifications
07/05/2023
10:00
14:00
Deleted message
(Message received at 09:59)
NO
NO
YES
NO
NO
NO
07/05/2023
10:02
14:02
Received message
And now here is the bad message for the 1:1.
Delete it, too.
Notifications
Notifications
NO
NO
NO
Notifications
07/05/2023
10:03
14:03
Deleted message
(Message received at 10:02)
NO
NO
NO
NO
NO
NO
07/05/2023
10:04
14:04
Sent message
Both messages are gone.
NO
YES
YES
NO
NO
NO
17/05/2023
10:49
14:49
Started sending dynamic location
NO
YES
YES
NO
NO
NO
17/05/2023
10:54
14:54
Stopped sending dynamic location
NO
NO
NO
NO
NO
NO
17/05/2023
10:55
14:55
Started receiving dynamic location
Notifications
YES
YES
NO
NO
Notifications
17/05/2023
11:00
15:00
Stopped receiving dynamic location
NO
NO
NO
NO
NO
NO
17/05/2023
11:02
15:02
Received static location
Notifications
YES
YES
NO
NO
Notifications
17/05/2023
11:05
15:05
Sent static location
NO
YES
YES
NO
NO
NO
The overall
results for each category and tool are shown in the following table.
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
Account Information
NO
YES
NO
NO
NO
NO
Contacts
NO
YES
NO
NO
NO
NO
Messages
Notifications
YES
YES
NO
NO
Notifications
Deleted message
Notifications
Notifications
NO
NO
NO
Notifications
Calls
NO
YES
YES
NO
NO
NO
Dynamic Location
NO
YES
YES
NO
NO
NO
Static location
NO
YES
YES
NO
NO
NO
Wire
Relevant
information for this application is stored in an SQLite database:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/AccountData/052477D9-0C43-4BEE-A934-CED86153E9CF/store/store.wiredatabase
Direct parsing of this application is supported
by OXYGEN and XAMN, but only XAMN parsed messages.
AXIOM, PA, and iLEAPP parsed some incoming
messages from iOS notifications. The deleted message was not recovered by
any of the tested tools.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
Date
Time (EDT)
Time (UTC)
Action
Message
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
02/05/2023
12:54
16:54
Received message
I switched over whenever you’re ready.
Notifications
Notifications
NO
YES
NO
Notifications
02/05/2023
12:57
16:57
Sent message
Awesome. What are you doing?
NO
NO
NO
YES
NO
NO
02/05/2023
12:58
16:58
Received message
Not much. Just got some lunch.
Notifications
Notifications
NO
YES
NO
Notifications
02/05/2023
13:00
17:00
Sent message
Just grabbed a bite myself. Eat and go.
NO
NO
NO
YES
NO
NO
02/05/2023
13:02
17:02
Received message
Same my dude.
Notifications
Notifications
NO
YES
NO
Notifications
02/05/2023
13:03
17:03
Sent message
How’s the testing going?
NO
NO
NO
YES
NO
NO
02/05/2023
13:05
17:05
Received message
(Reply to message sent at 13:03) Man, it’s one of
those days when I want to toss the workstation out of the window.
Notifications
Notifications
NO
YES
NO
Notifications
02/05/2023
13:07
17:07
Sent message
That good, eh?
NO
NO
NO
YES
NO
NO
02/05/2023
13:08
17:08
Received message
Absolutely not. (Red-Angry face emoji)
NO
NO
NO
YES
NO
NO
02/05/2023
13:47
17:47
Sent message
Sorry, got sidetracked. I’ll send you a picture.
NO
NO
NO
YES
NO
NO
02/05/2023
13:50
17:50
Sent picture
My contact
NO
NO
NO
YES
NO
NO
02/05/2023
13:52
17:52
Received message
Nice. I’ll send one in a minute.
Notifications
Notifications
NO
YES
NO
Notifications
02/05/2023
13:53
17:53
Received picture
Last day of 2023
Notifications
Notifications
NO
YES
NO
Notifications
02/05/2023
13:54
17:54
Saved picture
Last day of 2023
NO
NO
NO
YES
NO
NO
02/05/2023
14:09
18:09
Sent message
Got it. I’ll audio call you.
NO
NO
NO
YES
NO
NO
02/05/2023
14:10
18:10
Outgoing audio call
(1:40)
NO
NO
NO
YES
NO
NO
02/05/2023
14:12
18:12
Received message
My turn with the audio call.
Notifications
Notifications
NO
YES
NO
Notifications
02/05/2023
14:13
18:13
Incoming audio call
(1:35)
NO
NO
NO
YES
NO
NO
02/05/2023
14:15
18:15
Sent message
I’ll video call you now.
NO
NO
NO
YES
NO
NO
02/05/2023
14:16
18:16
Outoging video call
(1:30)
NO
NO
NO
YES
NO
NO
02/05/2023
14:18
18:18
Received message
I’ll video call you. Hang on.
Notifications
Notifications
NO
YES
NO
Notifications
02/05/2023
14:19
18:19
Incoming video call
(1:45)
NO
NO
NO
YES
NO
NO
03/05/2023
12:07
16:07
Received message
Here is your bad message. Let me know when you
delete it. I’ll feel better.
NO
NO
NO
NO
NO
NO
03/05/2023
12:08
16:08
Deleted message
(Message received at 12:07)
NO
NO
NO
NO
NO
NO
03/05/2023
12:10
16:10
Sent message
It’s gone. You can releax.
NO
NO
NO
YES
NO
NO
17/05/2023
10:40
14:40
Sent static location
NO
NO
NO
YES
NO
NO
17/05/2023
10:44
14:44
Received static location
Notifications
Notifications
NO
YES
NO
Notifications
The overall
results for each category and tool are shown in the following table.
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
Account Information
NO
NO
YES
YES
NO
NO
Contacts
NO
NO
YES
YES
NO
NO
Messages
Notifications
Notifications
NO
YES
NO
Notifications
Deleted message
NO
NO
NO
NO
NO
NO
Calls
NO
NO
NO
YES
NO
NO
Devices
NO
NO
YES
NO
NO
NO
Static location
NO
NO
NO
YES
NO
NO
Final Comments
Some final comments after this
complex post.
Most of the commonly used social
networking and chat applications are supported by most if not all the tested
tools.
The following table is an overview
of which tools parsed which applications. Be careful in evaluating the quality
of extracted data, as in some cases tools have a very limited parsing
capability (i.e., extracting the user account information).
Some apps are correctly and
completely supported only by a subset of tools. For example: Session and Wickr are
only parsed by PA; MeWe, Mastodon, Silent Phone, and Wire are only parsed by
XAMN; BeReal and Google Voice are only parsed by OXYGEN; and Burner is only
parsed by AXIOM and OXYGEN. The only completely unsupported app in the dataset
is Truth Social.
App Name
AXIOM
PA
OXYGEN
XAMN
BELKASOFT
ILEAPP
BeReal
NO
NO
YES
NO
NO
NO
Burner
YES
NO
YES
NO
NO
NO
Clubhouse
NO
YES
YES
NO
NO
NO
Discord
YES
YES
YES
YES
NO
YES
Facebook Messenger
YES
YES
YES
YES
YES
YES
Google Chat
NO
NO
YES
NO
YES
NO
Google Meet
YES
NO
YES
YES
NO
YES
Google Voice
NO
NO
YES
NO
NO
NO
GroupMe
YES
YES
YES
YES
NO
NO
imo HD
YES
NO
NO
NO
YES
YES
Instagram
YES
YES
YES
YES
YES
YES
kik
YES
YES
YES
YES
YES
YES
Line
YES
YES
YES
YES
YES
NO
Mastodon
NO
NO
NO
YES
NO
NO
MeWe
NO
NO
NO
YES
NO
NO
Session
NO
YES
NO
NO
NO
NO
Signal
YES
YES
YES
YES
NO
NO
Silent Phone
NO
NO
YES
YES
NO
NO
Skype
YES
YES
YES
YES
YES
NO
Snapchat
YES
YES
YES
YES
YES
NO
Telegram
YES
YES
YES
YES
YES
YES
Threema
YES
YES
YES
YES
NO
NO
TikTok
YES
YES
YES
YES
YES
YES
Truth Social
NO
NO
NO
NO
NO
NO
Twitter
YES
YES
YES
YES
YES
NO
Viber
YES
YES
YES
YES
YES
YES
WhatsApp
YES
YES
YES
YES
YES
YES
Wickr Pro (AWS
Wickr)
NO
YES
YES
NO
NO
NO
Wire
NO
NO
YES
YES
NO
NO
While doing the comparison, I
noticed that tools have often issues when parsing calls (sometimes they are not
able to differentiate between audio and video calls or fail in parsing the
length of the call), sharing of static and dynamic locations, and message
reactions. Also, most tools don’t show message threads in the correct way, and
this could complicate the job of an analyst.
Deleted messages were recovered from
the native SQLite database for 6 applications: Facebook Messenger, imoHD, kikMessenger, Line, Skype, Signal, and Threema. When the deleted message is an
incoming message, you can still have luck by analyzing parsed notifications: in
the tested scenario, deleted messages were found in notifications for Google
Voice, MeWe, Signal, Silent Phone (only metadata), Twitter, Viber, and WhatsApp.
It’s important to highlight that is
relevant, for an examiner, to know the application under investigation. Some
applications have specific features that should be analyzed on a case-by-case
basis: some examples are Instagram Posts and Stories, X/Twitter Tweets,
Snapchat Memories, and so on.
That’s all for this episode! The
next one will be about browsers, email clients, and productivity applications!
Relevant information for this application is
stored in an SQLite:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/ThreemaData.sqlite
Direct parsing of this application is supported
by PA, OXYGEN, and XAMN. Most of the tools were able to correctly parse most of the relevant
information. The deleted message was
recovered by OXYGEN and XAMN from the SQLite database.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
30/04/2023 |
15:42 |
19:42 |
Set profile picture |
HAL |
NO |
NO |
YES |
NO |
NO |
NO |
|
30/04/2023 |
15:43 |
19:43 |
Sent message |
What’s up?! |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
15:44 |
19:44 |
Received message |
Not much. Watching Bluey. Kid loves it. |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
15:46 |
19:46 |
Sent message |
Awesome. Which episode? |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
15:47 |
19:47 |
Received message |
The one where Chillie chases the kids and her dad
in the woods. |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
15:49 |
19:49 |
Sent message |
That’s a good one. My favorite is when Bandit
takes the kids to get Chinese takeout. |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
15:50 |
19:50 |
Received message |
That’s a good one. So is the date night episode. |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
15:51 |
19:51 |
Sent message |
Agreed. Send me a picture? |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
15:52 |
19:52 |
Received message |
(Reply to message sent at 15:51) Yep. Give me a
minute to find one. |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
15:58 |
19:58 |
Received picture |
Healthy Burgers |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
16:00 |
20:00 |
Sent message |
That’s great. I’ll send one. |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
16:02 |
20:02 |
Sent picture |
Food weapons |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
16:04 |
20:04 |
Received message |
I’ll call you in a minute. |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
16:05 |
20:05 |
Reacted to message |
(Message received at 16:04) (green thumbs up) |
NO |
NO |
NO |
NO |
NO |
NO |
|
30/04/2023 |
16:06 |
20:06 |
Incoming audio call |
(1:45) |
NO |
YES |
YES |
NO |
NO |
NO |
|
30/04/2023 |
16:09 |
20:09 |
Sent message |
My turn. I’ll audio call you. |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
16:11 |
20:11 |
Outgoing audio call |
(1:50) |
NO |
YES |
YES |
NO |
NO |
NO |
|
30/04/2023 |
16:14 |
20:14 |
Received message |
Let’s try video calls. I’ll go first. |
Notifications |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
16:37 |
20:37 |
Incoming video call |
(1:35) |
NO |
YES |
YES |
NO |
NO |
NO |
|
30/04/2023 |
16:54 |
20:54 |
Sent message |
My turn. |
NO |
YES |
YES |
YES |
NO |
NO |
|
30/04/2023 |
16:55 |
20:55 |
Outgoing video call |
(1:40) |
NO |
YES |
YES |
NO |
NO |
NO |
|
30/04/2023 |
16:59 |
20:59 |
Received message |
Please delete this message when you get it. I
don’t want anyone to see it. |
NO |
NO |
YES |
YES |
NO |
NO |
|
30/04/2023 |
17:00 |
21:00 |
Deleted message |
(Message received at 16:59) |
NO |
NO |
YES |
YES |
NO |
NO |
|
30/04/2023 |
17:01 |
21:01 |
Sent message |
It’s been handled (Smiley face emoji) |
NO |
YES |
YES |
YES |
NO |
NO |
|
17/05/2023 |
10:09 |
14:09 |
Sent static location |
|
NO |
YES |
YES |
YES |
NO |
NO |
|
17/05/2023 |
10:14 |
14:14 |
Received static location |
|
NO |
YES |
YES |
YES |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
YES |
YES |
YES |
YES |
NO |
NO |
|
Contacts |
NO |
YES |
YES |
YES |
NO |
NO |
|
Messages |
NO |
YES |
YES |
YES |
NO |
NO |
|
Deleted message |
NO |
NO |
YES |
YES |
NO |
NO |
|
Calls |
NO |
YES |
YES |
NO |
NO |
NO |
|
Locations |
NO |
YES |
YES |
YES |
NO |
NO |
|
Cache |
NO |
NO |
NO |
NO |
NO |
NO |
TikTok
Relevant information for this application is
stored in these files:
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/AwemeIM.db
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Application Support/ChatFiles/<User-Id>/db.sqlite
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/AWEStorage/UnifyStorage.sqlite
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Documents/kAWEPublishLocalVideoStorageFolder/
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/TTPlayerCache/
Direct parsing of this application is supported
by all tested tools.
Some differences were found in parsing capabilities.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
17/05/2023 |
08:42 |
12:42 |
Added profile picture |
HAL |
NO |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
10:37 |
14:37 |
Sent message |
Good morning. You around? |
YES |
YES |
YES |
YES |
YES |
YES |
|
20/05/2023 |
10:38 |
14:38 |
Received message |
(Reply to message sent at 10:37). I am. Good
morning! |
YES |
YES |
YES |
YES |
YES |
YES |
|
20/05/2023 |
10:39 |
14:39 |
Liked message |
(Message received at 10:38) |
NO |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
10:44 |
14:44 |
Sent message |
Awesome. Any plans for the day? |
YES |
YES |
YES |
YES |
YES |
YES |
|
20/05/2023 |
10:45 |
14:45 |
Received message |
Nope. You? |
YES |
YES |
YES |
YES |
YES |
YES |
|
20/05/2023 |
10:46 |
14:46 |
Sent message |
I am going to try to finish this image today.
Have a few map-related things to do. |
YES |
YES |
YES |
YES |
YES |
YES |
|
20/05/2023 |
10:47 |
14:47 |
Received message |
Did you finish Snapchat? |
YES |
YES |
YES |
YES |
YES |
YES |
|
20/05/2023 |
10:48 |
14:48 |
Sent message |
No. Also on the list. |
YES |
YES |
YES |
YES |
YES |
YES |
|
20/05/2023 |
11:02 |
15:02 |
Received message |
Better get to work then! |
YES |
YES |
YES |
YES |
YES |
YES |
|
20/05/2023 |
11:03 |
15:03 |
Sent message |
I know. (upside down smiley face emoji) |
YES |
YES |
YES |
YES |
YES |
YES |
|
20/05/2023 |
14:03 |
18:03 |
Took picture |
Coke & notes (with #work) |
NO |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
14:04 |
18:04 |
Posted picture |
(Taken at 14:03) |
NO |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
14:06 |
18:06 |
Other party liked post |
(Posted at 14:04) |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
20/05/2023 |
14:07 |
18:07 |
Other party commented on post |
(Posted at 14:04) Shouldn’t you be off today? |
NO |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
14:08 |
18:08 |
Replied to comment |
(Comment received at 14:07) I should be. Lol. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
20/05/2023 |
14:12 |
18:12 |
Liked other paty's post |
|
NO |
NO |
NO |
NO |
NO |
NO |
|
20/05/2023 |
14:13 |
18:13 |
Commented on other paty's post |
Don’t be lame. (ROFL emoji) |
NO |
NO |
NO |
NO |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
YES |
YES |
NO |
YES |
YES |
YES |
|
Contacts |
YES |
YES |
NO |
NO |
YES |
YES |
|
Groups |
NO |
NO |
NO |
YES |
NO |
NO |
|
Messages |
YES |
YES |
YES |
YES |
YES |
YES |
|
Media |
YES |
YES |
YES |
YES |
YES |
NO |
Truth Social
Relevant information for this application is
stored in an SQLite:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/chat/v1/<User-ID>/ChatModel.sqlite
Attachments
are stored in this folder:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/chat/v1/<User-ID>/Attachments
None of
the compared tools had a parser for this application, so messages and contacts were not
parsed by any tool. Some received messages were recovered by AXIOM, PA, XAMN,
and iLEAPP in iOS notifications.
Following
is the comparison table with the details of each action documented by Josh in
the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
05/05/2023 |
16:52 |
20:52 |
Login |
|
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
16:53 |
20:53 |
Accepted friend request |
(From @lizdehner) |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
16:54 |
20:54 |
Changed message retention to 90 days |
|
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
16:59 |
20:59 |
Sent message |
You here yet? |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
17:00 |
21:00 |
Received message |
I am! What are you doing? |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
17:21 |
21:21 |
Sent message |
Not much. Winding down for the day. Also need to
figure out dinner. |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
17:22 |
21:22 |
Other party reacted to message |
(Message sent at 17:21) (Thumb’s up emoji) |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
17:23 |
21:23 |
Received message |
I’m right there with you. I looked at the food
truck rodeo but there wasn’t anything I wanted. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
17:24 |
21:24 |
Sent message |
Same here. I was leaning towards the waffle truck
but decided against it. Too crowded for waffles. Lol. |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
17:26 |
21:26 |
Received message |
Completely agree with the crowd. Too much of a
hassle. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
17:28 |
21:28 |
Sent message |
Give me a minute and I’ll send you a picture. |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
17:30 |
21:30 |
Sent picture |
Furniture at 4 am |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
17:31 |
21:31 |
Received message |
I stayed in a hotel that had that type of chair.
It was creepy. I’ll send you one. Hang on. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
17:32 |
21:32 |
Received picture |
Updating the firmware |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
17:33 |
21:33 |
Saved picture |
Updating the firmware |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
17:34 |
21:34 |
Sent message |
Ha! That’s great! |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
17:35 |
21:35 |
Received message |
Please delete this bad message when you get it.
And let me know. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
05/05/2023 |
17:37 |
21:37 |
Deleted message |
(Message received at 17:35) |
NO |
NO |
NO |
NO |
NO |
NO |
|
05/05/2023 |
17:38 |
21:38 |
Sent message |
It’s been deleted. |
NO |
NO |
NO |
NO |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
NO |
NO |
NO |
NO |
|
Contacts |
NO |
NO |
NO |
NO |
NO |
NO |
|
Messages |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
Deleted message |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
Cache |
NO |
NO |
NO |
NO |
NO |
NO |
Relevant information for this application is
stored in these files:
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Caches/com.atebis.tweetie.direct-message.cache/<User-Id>
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/TSFModelCache.1/<User-Id>/modelCache.sqlite3
Direct parsing of this application is supported
by all tested tools.
Some differences were found in parsing capabilities. The deleted message was
not recovered from the SQLite database, but it was still available in iOS notifications.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
02/05/2023 |
10:47 |
14:47 |
Sent message |
Hey, are you here? |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
10:48 |
14:48 |
Received message |
I am. About time you came over. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
02/05/2023 |
10:49 |
14:49 |
Sent message |
Sorry. I have been a bit slow all morning. |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
10:50 |
14:50 |
Received message |
No worries. I was just kidding anyway. How’s the
morning been? |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
02/05/2023 |
10:51 |
14:51 |
Sent message |
Not too bad. One meeting, one canceled meeting,
and one meeting that apparently wasn’t. |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
10:53 |
14:53 |
Received message |
Same same. I’ll add that I’m waiting for an
extraction to finish parsing. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
02/05/2023 |
10:54 |
14:54 |
Sent message |
Me, too. Mine is a do-over. PA got stuck the
first time. |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
10:55 |
14:55 |
Other party reacted to message |
(Message sent at 10:54) (Thumbs down emoji) |
NO |
Notifications |
YES |
Notifications |
YES |
Notifications |
|
02/05/2023 |
10:56 |
14:56 |
Received message |
Ugh. I hate it when that happens. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
02/05/2023 |
10:57 |
14:57 |
Sent message |
It happens. Here comes a picture. |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
10:59 |
14:59 |
Sent picture |
Sorry I’m late |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
11:00 |
15:00 |
Received message |
Ha! Appropriate. I’ll send one now. |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
02/05/2023 |
11:01 |
15:01 |
Received picture |
Wizard of Oz |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
11:03 |
15:03 |
Sent message |
Lol. |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
11:04 |
15:04 |
Received message |
Here is your bad message. Please let me know when
you delete it. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
02/05/2023 |
11:05 |
15:05 |
Deleted message |
(Message received at 11:04) |
NO |
NO |
NO |
NO |
NO |
NO |
|
02/05/2023 |
11:06 |
15:06 |
Sent message |
Done. It’s been trashed (trash can emoji) |
YES |
YES |
YES |
YES |
YES |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
YES |
YES |
YES |
YES |
NO |
|
Users |
YES |
YES |
YES |
YES |
YES |
NO |
|
Messages |
YES |
YES |
YES |
YES |
YES |
Notifications |
|
Deleted message |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
Cache |
NO |
NO |
YES |
YES |
NO |
NO |
Viber
Relevant
information for this application is stored in two SQLite databases:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/com.viber/database/Contacts.data
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/com.viber/settings/Settings.data
Attachments
are saved in this path:
- /private/var/mobile/Containers/Data/Application/<GUID>/Documents/Attachments
Direct parsing of this application is supported
by all tested tools.
Most of the tools were able to correctly parse most of the relevant
information. The deleted message was
not recovered from the SQLite database, but it was still available in iOS
notifications.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
02/05/2023 |
11:12 |
15:12 |
Sent message |
You here? |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:13 |
15:13 |
Received message |
I am. Long time no see. Lol. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:15 |
15:15 |
Sent message |
How’s the new switch? |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:16 |
15:16 |
Received message |
You mean the replacement for the new switch?
Good. A lot more headroom for the wattage. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:17 |
15:17 |
Liked message |
(Message received at 11:16) |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:18 |
15:18 |
Replied to message |
(Message received at 11:16) How bad was it? |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:19 |
15:19 |
Received message |
I had one AP that would spike occasionally and
push it over the threshold. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:21 |
15:21 |
Sent message |
What would happen? |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:22 |
15:22 |
Received message |
The AP would just reboot. Basically nothing would
connect to it because it wouldn’t stay up long enough. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:24 |
15:24 |
Sent message |
That sucks. Want to send me a picture? |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:25 |
15:25 |
Received message |
Sure. Give me a minute to find one. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:26 |
15:26 |
Received picture |
Try a reboot |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:28 |
15:28 |
Sent message |
Got it. I’ll send one in a moment. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:31 |
15:31 |
Sent picture |
Clippy |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:32 |
15:32 |
Received message |
Nice, and possibly true. I’ll audio call you. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:33 |
15:33 |
Incoming audio call |
(1:35) |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:36 |
15:36 |
Sent message |
My turn. I’ll audio call you. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:37 |
15:37 |
Outgoing audio call |
(1:50) |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:40 |
15:40 |
Received message |
Here comes a video call. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:41 |
15:41 |
Incoming video call |
(1:56) |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:45 |
15:45 |
Sent message |
Ok, here comes your video call. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:46 |
15:46 |
Outgoing video call |
(1:35) |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:49 |
15:49 |
Received message |
Here is your bad message. Let me know when you
delete it. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
02/05/2023 |
11:50 |
15:50 |
Deleted message |
(Message received at 11:49) |
NO |
NO |
NO |
NO |
NO |
NO |
|
02/05/2023 |
11:51 |
15:51 |
Sent message |
It’s gone. You’re covered. |
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
10:17 |
14:17 |
Sent static location |
|
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
10:21 |
14:21 |
Received static location |
|
YES |
YES |
YES |
YES |
YES |
YES |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
YES |
YES |
YES |
YES |
YES |
|
Contacts |
NO |
YES |
YES |
YES |
YES |
YES |
|
Messages |
YES |
YES |
YES |
YES |
YES |
YES |
|
Deleted message |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
Calls |
YES |
YES |
YES |
YES |
YES |
YES |
|
Locations |
YES |
YES |
YES |
YES |
YES |
NO |
Relevant
information for this application is stored in these files and folders:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/Library/Preferences/group.net.whatsapp.WhatsApp.shared.plist
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/ContactsV2.sqlite
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/ChatStorage.sqlite
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/CallHistory.sqlite
Direct parsing of this application is supported
by all tested tools.
Most of the tools were able to correctly parse most of the relevant
information. The deleted message was
not recovered from the SQLite database, but it was still available in iOS notifications.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
02/05/2023 |
11:55 |
15:55 |
Added profile picture |
HAL |
NO |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
11:56 |
15:56 |
Sent message |
I’m here! |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:57 |
15:57 |
Received message |
Awesome. You had some chat history, eh? |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:58 |
15:58 |
Sent message |
Yep. I don’t recall setting it to back up, but
who knows. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
11:59 |
15:59 |
Received message |
Makes sense with all the test data you generate. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:00 |
16:00 |
Reacted to message |
(Message received at 11:59) (Thumbs up emoji) |
NO |
NO |
NO |
NO |
NO |
NO |
|
02/05/2023 |
12:01 |
16:01 |
Replied to message |
(Message received at 11:59) I do generate quite a
bit. I need to up my storage. A lot. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:02 |
16:02 |
Received message |
QNAP is the way, my friend. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:03 |
16:03 |
Sent message |
That’s what I keep hearing. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:04 |
16:04 |
Received message |
You listen to good people then. Lol. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:05 |
16:05 |
Sent message |
I do. Lol. I’ll send a picture. Just a moment. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:06 |
16:06 |
Sent picture |
Mario Kart |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:07 |
16:07 |
Received message |
Accurate. Alright, I’ll send you one now. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:09 |
16:09 |
Received picture |
Assault Cow |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:11 |
16:11 |
Sent message |
Nice. I’ll audio call you. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:12 |
16:12 |
Outgoing audio call |
(1:35) |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
12:14 |
16:14 |
Received message |
Now it’s my turn to audio call you. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:15 |
16:15 |
Incoming audio call |
(1:41) |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
12:19 |
16:19 |
Sent message |
Here comes a video call. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:20 |
16:20 |
Outgoing video call |
(1:45) |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
12:23 |
16:23 |
Received message |
My turn. Here comes a video call. |
YES |
YES |
YES |
YES |
YES |
YES |
|
02/05/2023 |
12:24 |
16:24 |
Incoming video call |
(1:44) |
YES |
YES |
YES |
YES |
YES |
NO |
|
02/05/2023 |
12:27 |
16:27 |
Received message |
You can delete this message. Let me know when you
do. |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
02/05/2023 |
12:29 |
16:29 |
Deleted message |
(Message received at 12:27) |
NO |
NO |
NO |
NO |
NO |
NO |
|
02/05/2023 |
12:31 |
16:31 |
Sent message |
Done. It’s gone. (Smiley face emoji) |
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
10:22 |
14:22 |
Started sending dynamic location |
|
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
10:27 |
14:27 |
Stopped sending dynamic location |
|
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
10:28 |
14:28 |
Started receiving dynamic location |
|
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
10:33 |
14:33 |
Stopped receiving dynamic location |
|
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
10:35 |
14:35 |
Sent static locaion |
|
YES |
YES |
YES |
YES |
YES |
YES |
|
17/05/2023 |
10:36 |
14:36 |
Received static location |
|
YES |
YES |
YES |
YES |
YES |
YES |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
YES |
YES |
YES |
YES |
YES |
NO |
|
Contacts |
YES |
YES |
YES |
YES |
YES |
YES |
|
Groups |
YES |
YES |
YES |
YES |
YES |
NO |
|
Messages |
YES |
YES |
YES |
YES |
YES |
YES |
|
Deleted message |
Notifications |
Notifications |
NO |
Notifications |
NO |
Notifications |
|
Calls |
YES |
YES |
YES |
YES |
YES |
NO |
|
Dynamic Locations |
YES |
YES |
YES |
YES |
YES |
YES |
|
Static Locations |
YES |
YES |
YES |
YES |
YES |
YES |
WickrPro
Relevant information for this app is stored in
an SQLite database:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/wickrLocal.sqlite
Other relevant files and folders are:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/Logs
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Preferences/com.wickr.pro.prod.plist
- /private/var/mobile/Containers/Data/Application/<GUID>/Library/Logs
The SQLite database is encrypted, and PA is the
only tool with a decryption and parsing feature for this database. Oxygen parses the database and extracts messages and calls metadata, but without decryption of the content.
AXIOM and iLEAPP parsed some incoming messages from iOS notifications but
without text. The deleted message was not recovered by any of the tested
tools.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
07/05/2023 |
08:55 |
12:55 |
Sent message |
Good morning! |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
08:56 |
12:56 |
Received message |
Good morning to you as well. What are you doing? |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
08:58 |
12:58 |
Sent message |
Not much. Got up and cooked breakfast this
morning. Now everyone has run off. |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
08:59 |
12:59 |
Received message |
Makes sense. They’re all full and you’re not
useful anymore. Lol. |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
09:03 |
13:03 |
Sent message |
Ok, that’s fair. (Smiley face emoji) |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:04 |
13:04 |
Received message |
(Reply to message sent at 09:03) You’re such a
good sport. |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
09:05 |
13:05 |
Sent message |
I try. That’s all I can do. |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:07 |
13:07 |
Received message |
I have a good meme. Let me find where I put it
and I’ll send it to you. |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
09:09 |
13:09 |
Reacted to message |
(Message received at 09:07) (Thumbs up emoji) |
NO |
NO |
NO |
NO |
NO |
NO |
|
07/05/2023 |
09:10 |
13:10 |
Received picture |
East vs. West |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
09:13 |
13:13 |
Sent message |
Oh man, that’s awesome. Let me find one. Give me
a moment. |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:14 |
13:14 |
Sent picture |
Mediocretes |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:18 |
13:18 |
Received message |
Ha! Nice. I’ll audio call you. |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
09:20 |
13:20 |
Incoming audio call |
(1:45) |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:23 |
13:23 |
Sent message |
I’ll audio call you now. |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:24 |
13:24 |
Outgoing audio call |
(1:40) |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:27 |
13:27 |
Received message |
Here comes a video call. |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
09:28 |
13:28 |
Incoming video call |
(2:00) |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:32 |
13:32 |
Sent message |
Here comes your video call. |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:33 |
13:33 |
Outgoing video call |
(2:05) |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:37 |
13:37 |
Sent message |
I’ll see about creating a room. Give me a few
minutes. |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:38 |
13:38 |
Created room |
(Room name: iOS 15 Room) |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:40 |
13:40 |
Sent message |
You here? |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:42 |
13:42 |
Received message |
I am. Let’s make this quick. I’ll send you a
picture. |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
09:44 |
13:44 |
Received picture |
Eternal enemy |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
09:46 |
13:46 |
Sent message |
Got it. I’ll send you one now. |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:49 |
13:49 |
Sent picture |
Clicked on the link |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:50 |
13:50 |
Received message |
Nice. I’ll audio call you. |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
09:51 |
13:51 |
Incoming meeting call |
(1:43) |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:55 |
13:55 |
Sent message |
These just look like meetings. I’ll call you and
then we’ll call that part done. |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:56 |
13:56 |
Outgoing meeting call |
(1:40) |
NO |
YES |
YES |
NO |
NO |
NO |
|
07/05/2023 |
09:59 |
13:59 |
Received message |
Here is your bad message for the room. Please
delete it. |
Notifications |
Notifications |
YES |
NO |
NO |
Notifications |
|
07/05/2023 |
10:00 |
14:00 |
Deleted message |
(Message received at 09:59) |
NO |
NO |
YES |
NO |
NO |
NO |
|
07/05/2023 |
10:02 |
14:02 |
Received message |
And now here is the bad message for the 1:1.
Delete it, too. |
Notifications |
Notifications |
NO |
NO |
NO |
Notifications |
|
07/05/2023 |
10:03 |
14:03 |
Deleted message |
(Message received at 10:02) |
NO |
NO |
NO |
NO |
NO |
NO |
|
07/05/2023 |
10:04 |
14:04 |
Sent message |
Both messages are gone. |
NO |
YES |
YES |
NO |
NO |
NO |
|
17/05/2023 |
10:49 |
14:49 |
Started sending dynamic location |
|
NO |
YES |
YES |
NO |
NO |
NO |
|
17/05/2023 |
10:54 |
14:54 |
Stopped sending dynamic location |
|
NO |
NO |
NO |
NO |
NO |
NO |
|
17/05/2023 |
10:55 |
14:55 |
Started receiving dynamic location |
|
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
17/05/2023 |
11:00 |
15:00 |
Stopped receiving dynamic location |
|
NO |
NO |
NO |
NO |
NO |
NO |
|
17/05/2023 |
11:02 |
15:02 |
Received static location |
|
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
17/05/2023 |
11:05 |
15:05 |
Sent static location |
|
NO |
YES |
YES |
NO |
NO |
NO |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
YES |
NO |
NO |
NO |
NO |
|
Contacts |
NO |
YES |
NO |
NO |
NO |
NO |
|
Messages |
Notifications |
YES |
YES |
NO |
NO |
Notifications |
|
Deleted message |
Notifications |
Notifications |
NO |
NO |
NO |
Notifications |
|
Calls |
NO |
YES |
YES |
NO |
NO |
NO |
|
Dynamic Location |
NO |
YES |
YES |
NO |
NO |
NO |
|
Static location |
NO |
YES |
YES |
NO |
NO |
NO |
Wire
Relevant
information for this application is stored in an SQLite database:
- /private/var/mobile/Containers/Shared/AppGroup/<GUID>/AccountData/052477D9-0C43-4BEE-A934-CED86153E9CF/store/store.wiredatabase
Direct parsing of this application is supported
by OXYGEN and XAMN, but only XAMN parsed messages.
AXIOM, PA, and iLEAPP parsed some incoming
messages from iOS notifications. The deleted message was not recovered by
any of the tested tools.
Following is the comparison table with the
details of each action documented by Josh in the creation of the image.
|
Date |
Time (EDT) |
Time (UTC) |
Action |
Message |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
02/05/2023 |
12:54 |
16:54 |
Received message |
I switched over whenever you’re ready. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
02/05/2023 |
12:57 |
16:57 |
Sent message |
Awesome. What are you doing? |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
12:58 |
16:58 |
Received message |
Not much. Just got some lunch. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
02/05/2023 |
13:00 |
17:00 |
Sent message |
Just grabbed a bite myself. Eat and go. |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
13:02 |
17:02 |
Received message |
Same my dude. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
02/05/2023 |
13:03 |
17:03 |
Sent message |
How’s the testing going? |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
13:05 |
17:05 |
Received message |
(Reply to message sent at 13:03) Man, it’s one of
those days when I want to toss the workstation out of the window. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
02/05/2023 |
13:07 |
17:07 |
Sent message |
That good, eh? |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
13:08 |
17:08 |
Received message |
Absolutely not. (Red-Angry face emoji) |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
13:47 |
17:47 |
Sent message |
Sorry, got sidetracked. I’ll send you a picture. |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
13:50 |
17:50 |
Sent picture |
My contact |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
13:52 |
17:52 |
Received message |
Nice. I’ll send one in a minute. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
02/05/2023 |
13:53 |
17:53 |
Received picture |
Last day of 2023 |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
02/05/2023 |
13:54 |
17:54 |
Saved picture |
Last day of 2023 |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
14:09 |
18:09 |
Sent message |
Got it. I’ll audio call you. |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
14:10 |
18:10 |
Outgoing audio call |
(1:40) |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
14:12 |
18:12 |
Received message |
My turn with the audio call. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
02/05/2023 |
14:13 |
18:13 |
Incoming audio call |
(1:35) |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
14:15 |
18:15 |
Sent message |
I’ll video call you now. |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
14:16 |
18:16 |
Outoging video call |
(1:30) |
NO |
NO |
NO |
YES |
NO |
NO |
|
02/05/2023 |
14:18 |
18:18 |
Received message |
I’ll video call you. Hang on. |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
02/05/2023 |
14:19 |
18:19 |
Incoming video call |
(1:45) |
NO |
NO |
NO |
YES |
NO |
NO |
|
03/05/2023 |
12:07 |
16:07 |
Received message |
Here is your bad message. Let me know when you
delete it. I’ll feel better. |
NO |
NO |
NO |
NO |
NO |
NO |
|
03/05/2023 |
12:08 |
16:08 |
Deleted message |
(Message received at 12:07) |
NO |
NO |
NO |
NO |
NO |
NO |
|
03/05/2023 |
12:10 |
16:10 |
Sent message |
It’s gone. You can releax. |
NO |
NO |
NO |
YES |
NO |
NO |
|
17/05/2023 |
10:40 |
14:40 |
Sent static location |
|
NO |
NO |
NO |
YES |
NO |
NO |
|
17/05/2023 |
10:44 |
14:44 |
Received static location |
|
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
The overall
results for each category and tool are shown in the following table.
|
|
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
Account Information |
NO |
NO |
YES |
YES |
NO |
NO |
|
Contacts |
NO |
NO |
YES |
YES |
NO |
NO |
|
Messages |
Notifications |
Notifications |
NO |
YES |
NO |
Notifications |
|
Deleted message |
NO |
NO |
NO |
NO |
NO |
NO |
|
Calls |
NO |
NO |
NO |
YES |
NO |
NO |
|
Devices |
NO |
NO |
YES |
NO |
NO |
NO |
|
Static location |
NO |
NO |
NO |
YES |
NO |
NO |
Final Comments
Some final comments after this
complex post.
Most of the commonly used social
networking and chat applications are supported by most if not all the tested
tools.
The following table is an overview
of which tools parsed which applications. Be careful in evaluating the quality
of extracted data, as in some cases tools have a very limited parsing
capability (i.e., extracting the user account information).
Some apps are correctly and
completely supported only by a subset of tools. For example: Session and Wickr are
only parsed by PA; MeWe, Mastodon, Silent Phone, and Wire are only parsed by
XAMN; BeReal and Google Voice are only parsed by OXYGEN; and Burner is only
parsed by AXIOM and OXYGEN. The only completely unsupported app in the dataset
is Truth Social.
|
App Name |
AXIOM |
PA |
OXYGEN |
XAMN |
BELKASOFT |
ILEAPP |
|
BeReal |
NO |
NO |
YES |
NO |
NO |
NO |
|
Burner |
YES |
NO |
YES |
NO |
NO |
NO |
|
Clubhouse |
NO |
YES |
YES |
NO |
NO |
NO |
|
Discord |
YES |
YES |
YES |
YES |
NO |
YES |
|
Facebook Messenger |
YES |
YES |
YES |
YES |
YES |
YES |
|
Google Chat |
NO |
NO |
YES |
NO |
YES |
NO |
|
Google Meet |
YES |
NO |
YES |
YES |
NO |
YES |
|
Google Voice |
NO |
NO |
YES |
NO |
NO |
NO |
|
GroupMe |
YES |
YES |
YES |
YES |
NO |
NO |
|
imo HD |
YES |
NO |
NO |
NO |
YES |
YES |
|
Instagram |
YES |
YES |
YES |
YES |
YES |
YES |
|
kik |
YES |
YES |
YES |
YES |
YES |
YES |
|
Line |
YES |
YES |
YES |
YES |
YES |
NO |
|
Mastodon |
NO |
NO |
NO |
YES |
NO |
NO |
|
MeWe |
NO |
NO |
NO |
YES |
NO |
NO |
|
Session |
NO |
YES |
NO |
NO |
NO |
NO |
|
Signal |
YES |
YES |
YES |
YES |
NO |
NO |
|
Silent Phone |
NO |
NO |
YES |
YES |
NO |
NO |
|
Skype |
YES |
YES |
YES |
YES |
YES |
NO |
|
Snapchat |
YES |
YES |
YES |
YES |
YES |
NO |
|
Telegram |
YES |
YES |
YES |
YES |
YES |
YES |
|
Threema |
YES |
YES |
YES |
YES |
NO |
NO |
|
TikTok |
YES |
YES |
YES |
YES |
YES |
YES |
|
Truth Social |
NO |
NO |
NO |
NO |
NO |
NO |
|
Twitter |
YES |
YES |
YES |
YES |
YES |
NO |
|
Viber |
YES |
YES |
YES |
YES |
YES |
YES |
|
WhatsApp |
YES |
YES |
YES |
YES |
YES |
YES |
|
Wickr Pro (AWS
Wickr) |
NO |
YES |
YES |
NO |
NO |
NO |
|
Wire |
NO |
NO |
YES |
YES |
NO |
NO |
Deleted messages were recovered from
the native SQLite database for 6 applications: Facebook Messenger, imoHD, kikMessenger, Line, Skype, Signal, and Threema. When the deleted message is an
incoming message, you can still have luck by analyzing parsed notifications: in
the tested scenario, deleted messages were found in notifications for Google
Voice, MeWe, Signal, Silent Phone (only metadata), Twitter, Viber, and WhatsApp.
It’s important to highlight that is
relevant, for an examiner, to know the application under investigation. Some
applications have specific features that should be analyzed on a case-by-case
basis: some examples are Instagram Posts and Stories, X/Twitter Tweets,
Snapchat Memories, and so on.
That’s all for this episode! The
next one will be about browsers, email clients, and productivity applications!
Comments
Post a Comment
